Appendix A: Specifications
A-8
AWG610 Arbitrary Waveform Generator User Manual
Table A-9: Period Jitter accuracy
Clock frequency 2.6 GS/s 1.6 GS/s 800 MS/s
Measurement StdDev Pk-Pk StdDev Pk-Pk StdDev Pk-Pk
Marker1 output 3.5 ps 16.0 ps 3.5 ps 16.0 ps 3.0 ps 14.0 ps
1/4 Clock output 4.5 ps 25.0 ps 4.5 ps 25.0 ps 4.0 ps 23.0 ps
Table A-10: Cycle to Cycle JItter accuracy
Clock frequency 2.6 GS/s 1.6 GS/s 800 MS/s
Measurement StdDev Pk-Pk StdDev Pk-Pk StdDev Pk-Pk
Marker1 output 5.5 ps 28.0 ps 5.5 ps 28.0 ps 5.5 ps 28.0 ps
1/4 Clock output 6.5 ps 37.0 ps 6.5 ps 37.0 ps 6.5 ps 37.0 ps
Table A-11: Auxiliary inputs
Characteristics Description PV reference page
Trigger input
5
Connector Rear panel BNC connector
Impedance 1kW or 50 W
Polarity POS (positive) or NEG (negative)
Input voltage range
"10V,intoa1kW load
"5V,intoa50W load
Threshold
Level -5.0 V to 5.0 V
n Accuracy
"(5 % of level + 0.1 V)
Page B-40
Resolution 0.1 V
Pulse width Minimum 10 ns, 0.2 V amplitude
Trigger dead time
x 576 clock + 450 ns
Delay to analog out, Typical 30 ns +22 clock (Triggered mode)
30 ns +880 clock (Gated mode)
Delay to marker, Typical 28 ns +22 clock
