Error Messages 59
ESG Family Signal Generators 201 to 702: Device-Specific Errors
Calibration failure; DCFM DC overrange
The instrument was unable to perform a DCFM or DCΦM calibration due
to the input signal being outside of the offset range that can be calibrated
for.
Calibration failure; I/Q cal.
While executing the internal I/Q calibration, the attempt to allocate
memory for the calibration failed.
Calibration failure; I/Q cal failed to allocate memory.
While executing the internal I/Q calibration, a failure occurred during the
section indicated.
Calibration failure; ‘Marble Cal’, ‘Offset Cal’, ‘Other Cal’,
‘Gain Cal’, ‘BBG Cal’, ‘ARB Cal’
While executing the internal I/Q calibration, a failure occurred during the
section indicated.
Calibration failure; Upgrade calibration failed. Data not
stored.
The calibration stage of the instrument upgrade was not executed
successfully. The calibration data has not been stored. The upgrade is not
functional. Report this error to the nearest Agilent Technologies sales or
service office.
518 Arbitrary Waveform Generator unlocked; refer to manual.
The instrument’s dual arbitrary waveform generator is unlocked. This
error will occur when the
ARB Reference key is set to Ext and there is no
external signal applied to the instrument. It may also occur if there is a
problem with the A5 dual arbitrary waveform generator board.
519 Uncalibrated signal; IQ Adjustments not calibrated. Refer to
manual.
A calibration is required to use the IQ adjustments feature. The I/Q
adjustments may be functional, but are not guaranteed to meet
specifications until an I/Q calibration is performed. Refer to the user’s
guide.
