Error Messages 57
ESG Family Signal Generators 201 to 702: Device-Specific Errors
The firmware has changed the attenuator setting because, while in
attenuator hold mode, a change in frequency setting has forced the ALC
beyond its range.
Attenuator hold setting over range; Power set to lower limit.
The firmware has changed the power setting to a value other than the
requested value due to the fact that, while in attenuator hold mode, the
user has requested a power setting that is below the ALC range for the
attenuator setting. The power has been set to the lower limit.
Attenuator hold setting over range; Power set to upper limit.
The firmware has changed the power setting to a value other than the
requested value due to the fact that, while in attenuator hold mode, the
user has requested a power setting that is above the ALC range for the
attenuator setting.
508 Frac-N Loop unlocked
The synthesizer is unlocked. Service may be needed.
Sampler Loop unlocked
The synthesizer is unlocked. Service may be needed.
YO Loop unlocked
The synthesizer is unlocked. Service may be needed.
509 Output Section input overdrive
Internal error: report to factory.
510 I/Q Modulator overdrive
Internal error: report to factory.
511 Output unleveled
The instrument’s output is unleveled.
512 Reference unlocked
The instrument’s reference is unlocked. If an external reference is
connected, check the frequency and power. It is possible for this to occur
during a poor connection/disconnection of an external reference. If this
error reoccurs when no external reference is connected, the instrument
may require service.
