26 Chapter 2
Basic Operation
Using Table Editors
Using Table Editors
Table editors simplify configuration tasks, such as creating a list sweep. This section provides information to
familiarize you with basic table editor functionality using the List Mode Values table editor as an example.
Press
Preset > Sweep/List > Configure List Sweep.
The signal generator displays the List Mode Values table editor, as shown below.
Figure 2-1
Active Function Area displays the active table item while its value is edited
Cursor an inverse video identifier used to highlight specific table items for
selection and editing
Table Softkeys select table items, preset table values, and modify table structures
Table Items values arranged in numbered rows and titled columns (The columns
are also known as data fields. For example, the column below the
Frequency title is known as the Frequency data field).
Cursor
Table Softkeys
Table Name
Table Items
Active Function Area
