E6581160
64
7
Q Default settings by inverter rating
Inverter type
Torque boost
value 1/2
Dynamic
braking
resistance
Dynamic
braking resistor
capacity
Automatic
torgue boost
value
Motor rated
current
Motor no-load
current
Motor
adjustment
coefficient
Over-voltage
stall protection
level
XD／H
(%)
H
(Ω) (Note)
H
(kW)
H
(%)
H
(A)
H
(%)
H H
(%)
VFS11S-2002PL 6.0 200.0 0.12 8.3 1.2 70 90 134
VFS11S-2004PL 6.0 200.0 0.12 6.2 2.0 65 90 134
VFS11S-2007PL 6.0 200.0 0.12 5.8 3.4 60 80 134
VFS11S-2015PL 6.0 75.0 0.12 4.3 6.2 55 70 134
VFS11S-2022PL 5.0 75.0 0.12 4.1 8.9 52 70 134
VFS11-2002PM 6.0 200.0 0.12 8.3 1.2 70 90 134
VFS11-2004PM 6.0 200.0 0.12 6.2 2.0 65 90 134
VFS11-2005PM 6.0 200.0 0.12 6.0 2.7 62 80 134
VFS11-2007PM 6.0 200.0 0.12 5.8 3.4 60 80 134
VFS11-2015PM 6.0 75.0 0.12 4.3 6.2 55 70 134
VFS11-2022PM 5.0 75.0 0.12 4.1 8.9 52 70 134
VFS11-2037PM 5.0 40.0 0.12 3.4 14.8 48 70 134
VFS11-2055PM 4.0 20.0 0.24 3.0 21.0 46 70 134
VFS11-2075PM 3.0 15.0 0.44 2.5 28.2 43 70 134
VFS11-2110PM 2.0 10.0 0.66 2.3 40.6 41 60 134
VFS11-2150PM 2.0 7.5 0.88 2.0 54.6 38 50 134
VFS11-4004PL 6.0 200.0 0.12 6.2 1.0 65 90 140
VFS11-4007PL 6.0 200.0 0.12 5.8 1.7 60 80 140
VFS11-4015PL 6.0 200.0 0.12 4.3 3.1 55 70 140
VFS11-4022PL 5.0 200.0 0.12 4.1 4.5 52 70 140
VFS11-4037PL 5.0 160.0 0.12 3.4 7.4 48 70 140
VFS11-4055PL 4.0 80.0 0.24 2.6 10.5 46 70 140
VFS11-4075PL 3.0 60.0 0.44 2.3 14.1 43 70 140
VFS11-4110PL 2.0 40.0 0.66 2.2 20.3 41 60 140
VFS11-4150PL 2.0 30.0 0.88 1.9 27.3 38 50 140
VFS11-6007P 3.0 285.0 0.06 3.8 1.1 61 80 134
VFS11-6015P 3.0 145.0 0.12 3.8 2.1 59 70 134
VFS11-6022P 3.0 95.0 0.18 3.2 3.0 54 70 134
VFS11-6037P 3.0 48.0 0.37 3.5 4.9 50 70 134
VFS11-6055P 2.0 29.0 0.61 2.0 7.3 55 70 134
VFS11-6075P 2.0 29.0 0.61 1.5 9.5 51 70 134
VFS11-6110P 2.0 19.0 0.92 1.9 14.5 55 60 134
VFS11-6150P 1.0 14.0 1.23 1.7 19.3 53 50 134
Note: Be sure to set f308 (Dynamic braking resistance) at the resistance of the dynamic braking resistor connected.
