E6581160
40
5
5.2 Display of trip information
5.2.1 Trip code display
If the inverter trips, an error code is displayed to suggest the cause. Since trip records are retained, information
on each trip can be displayed anytime in the status monitor mode.
For the kinds of causes that can be indicated in the event of a trip, see section 9.1.
5.2.2 Display of trip information at the occurrence of a trip
At the occurrence of a trip, the same information as that displayed in the mode described in 5.1.1, "Status monitor
under normal conditions," can be displayed, as shown in the table below, if the inverter is not turned off or reset.
To display trip information after turning off or resetting the inverter, follow the steps described in 5.1.2, "Display of
detailed information on a past trip."
Example of call-up of trip information
Item displayed
Key
operated
LED
display
Communic
ation No.
Description
Cause of trip
QR
Status monitor mode (The code blinks if a trip
occurs.)
The motor coasts and comes to a stop (coast stop).
Parameter setting
mode
CWJ
The first basic parameter “CWJ” (history function)
is displayed.
Direction of
rotation
HT-H FE01
The direction of rotation at the occurence of a trip
is displayed. (HTH: forward run, HTT:
reverser run).
Operation
frequency
command
H
FE02
The operation frequency command value (Hz/free
unit) at the occurrence of a trip is displayed.
Load current E FE03
The output power of the inverter at the occurrence
of a trip (%/A) is displayed.
Input voltage [ FE04
The inverter input (DC) voltage (%/V) at the
occurrence of a trip is displayed.
Output voltage
R
FE05
The output voltage of the inverter at the
occurrence of a trip (%/V) is displayed.
Torque
SQ
FE18
The torque at the occurrence of a trip (%) is
displayed.
Torque current
Y
FE20
The torque current (%/A) at the occurrence of a
trip is displayed.
Inverter load factor N FE27
The inverter load factor (%) at the occurrence of a
trip is displayed.
PBR cumulative
load factor
T FE25
The cumulative load factor (%) of the resistor at
the occurrence of a trip is displayed.
Input power k FE29
The inverter input power (kW) at the occurrence of
a trip is displayed.
Output power
J
FE30
The inverter output power (kW) at the occurrence
of a trip is displayed.
Operation
frequency
Z
FE00
The inverter output frequency (Hz/free unit) at the
occurrence of a trip is displayed.
(Continued overleaf)
MO
MOMO
MODE
DEDE
DE
MO
MOMO
MODE
DEDE
DE
Note 3
Note 2
Note 1
