E6581160
62
7
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference
E6581158
H
0710
Standard monitor
display selection
- - 0: Operation frequency (Hz/free unit)
1: Frequency command (Hz/free unit)
2: Output current (%/A)
3: Inverter rated current (A)
4: Inverter load factor (%)
5: Output power (%)
6: Frequency command after PID
control (Hz/free unit)
7: Optional item specified from an
external control unit
0 6.21.5
H
0719
Canceling of
operation
command when
standby terminal
(ST) is turned off
- - 0: Operation command canceled
(cleared)
1: Operation command retained
1 6.21.6
H
0721
Panel stop pattern
- - 0: Slowdown stop
1: Coast stop
0 6.21.7
H
0730
Prohibition of
frequency setting
on the operation
panel (HE)
- - 0: Permitted
1: Prohibited
0
H
0733
Panel operation
prohibition
(RUN/STOP keys)
- - 0: Permitted
1: Prohibited
0
H
0734
Prohibition of
panel emergency
stop operation
- - 0: Permitted
1: Prohibited
0
H
0735 Prohibition of
panel reset
operation
- - 0: Permitted
1: Prohibited
0
H
0736
Prohibition of
change of EOQF
/ HOQF during
operation
- - 0: Permitted
1: Prohibited
1
6.21.1
• Communication parameters
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference
E6581158
H
0800
Communication
rate
- - 0: 1200bps
1: 2400bps
2: 4800bps
3: 9600bps
4: 19200bps
3
H
0801
Parity
- - 0: NON (No parity)
1: EVEN (Even parity)
2: ODD (Odd parity)
1
H
0802
Inverter number
- 1/1 0-255 0
H
0803
Communication
error trip time
s 1/1 0: (disabled)
1-100
0
H
0805
Communication
waiting time
s 0.01/0.01 0.00-2.00 0.00
H
0806
Setting of master
and slave for
communication
between inverters
- - 0: Slave (0 Hz command issued in
case the master inverter fails)
1: Slave (Operation continued in case
the master inverter fails)
2: Slave (Emergency stop tripping in
case the master inverter fails)
3: Master (transmission of frequency
commands)
4: Master (transmission of output
frequency signals)
0
6.22
