Installing the Software
19
2
A Quit all applications running.
B Insert the CD-ROM into the CD-
ROM drive.
Auto Run will start the installer.
C Select a language for the interface
language, and then click [OK].
The following languages are availa-
ble: Cestina (Czech), Dansk (Dan-
ish), Deutsch (German), English
(English), Espanol (Spanish), Fran-
cais (French), Italiano (Italian), Ko-
rean (Korean) Magyar (Hungarian),
Nederlands (Dutch), Norsk (Nor-
wegian), Polski (Polish), Portugues
(Portuguese), Russian (Russian),
Suomi (Finnish), Svenska (Swed-
ish)
The default interface language is
English.
D Click [PCL/RPCS Printer Drivers].
The software license agreement
appears in the [License Agreement]
dialog box.
E After reading through the agree-
ment, click [I accept the agreement]
to agree, and then click [Next].
F Select the printer drivers you
want to install when the [Select
Program] dialog box appears, and
then click [Next].
G Select the model of the machine
you are using.
To change the printer name,
change it in the [Change settings for
'Printer Name'] box.
H Double-click the machine name
to display the printer settings.
I Select SmartNetMonitor.
SmartNetMonitor
A
Click
[
Port:
]
, and then click
[
Add
]
.
B Click [SmartNetMonitor], and
then click [OK].
C Select the machine you want to
use.
TCP/IP
A Click [TCP/IP], and then
click [Search].
Available machines will
be listed.
B Select the machine you
want to use, and then click
[OK].
Note
Machines that respond to
an IP broadcast from the
computer will be dis-
played. To print to a ma-
chine not listed here, click
[Specify Address], and then
enter the IP address or
host name.
Under Windows 95/98/Me,
avoid using an address that is
partially similar to one al-
ready in use. For example, if
“
192.168.0.2
” is already
used, “192.168.0.2xx” cannot
be used. Similarly, if
“192.168.0.20” is already
used, “
192.168.0.2
” cannot
be used.
NetBEUI
A Click [NetBEUI], and then
click [Search].
A list of machines that can
be used with NetBEUI ap-
pears.
B Select the machine you
want to use, and then click
[OK].
