Specifications
199
11
Limitation
r There may be a difference in the size of the image when it is printed at the des-
tination.
r If you place an original larger than A3, 11"×17" on the exposure glass, only an
A3, 11"×17" area is scanned.
Note
r Even if an original is correctly placed on the exposure glass or in the ADF, a
margin of 3 mm (0.1") around each edge of the original may not be sent.
r If the receiver uses paper of a smaller width than the original, the image will
be reduced to fit that paper. See p.74 “Auto Reduce”.
r The machine detects paper sizes in the following ways:
• When you place an original in the ADF, an original wider than about 264
mm (10.4") is scanned as A3, 11"×17" size.
An original narrower than about 230 mm (9.1") will be sent as 8
1
/
2
"×11" or
8
1
/
2
"×14" size, and an original narrower than about 264 mm (10.4”) is
scanned as B4 JIS.
Originals up to 1,200 mm (47.2") in length can be scanned.
• Refer to the table below for sizes the machine can detect when you place
an original on the exposure glass. Because the machine scans non-standard
size documents in a standard size, part of the image may be truncated de-
pending on the length of the document. For details about how to set non-
standard size documents, see p.18 “Setting a Scan Area”, Facsimile Refer-
ence <Basic Features>.
v Metric Version
v Inch Version
× - Unable to auto detect
*1
Normally a length of about 420 mm (16.5") can be scanned; however, it is only possi-
ble to specify a scanning size up to 432 mm (17").
Length
*1
-249 mm 249 mm-274 mm 274 mm-316 mm 316 mm-
Width
-243 mm × B5 JISL A4L FL
243 mm-
268 mm
B5 JISK B4 JISL B4 JISL B4 JISL
268 mm- A4K A3L A3L A3L
Length
*1
-9.8" 9.8"-10.8" 10.8"-12.4" 12.4"-
Width
-9.6" × × 8
1
/
2
"×11"L FL
9.6"-10.6" 11"×8
1
/
2
"K 11"×17"L 11"×17"L 11"×17"L
10.6"- 11"×8
1
/
2
"K 11"×17"L 11"×17"L 11"×17"L
