Setting Up the Machine on a Network
36
3
❖
❖❖
❖ Effective Protocol
Select the protocol to use in the
network.
• TCP/IP:Effective/Invalid
• NetWare:Effective/Invalid
• SMB:Effective/Invalid
• AppleTalk:Effective/Invalid
Note
❒ Default: TCP/IP:Effective, Net-
Ware:Effective, SMB:Effective,
AppleTalk:Effective
❖
❖❖
❖ Host Name
Specify the host name.
❖
❖❖
❖ Domain Name
Specify the domain name.
Interface Settings/IEEE 1394
Preparation
You must install the IEEE 1394 in-
terface board (optional) in the ma-
chine.
❖
❖❖
❖ IP Address
When you connect the machine to
a network using the IEEE 1394 in-
terface, you must configure the IP
address and subnet mask.
• Auto-Obtain (DHCP)
• Specify
When you select [Specify], enter
the [IP Address] and [Sub-net
Mask] as “xxx.xxx.xxx.xxx”(“x”
indicates a number).
• IP Address: 011.022.033.044
• Sub-net Mask: 000.000.000.000
Note
❒ Default: Auto-Obtain (DHCP)
❒ If you use the interface for Eth-
ernet and IEEE 1394 (IP over
1394) at the same time, settings
must be made carefully. See
p.104 “Using DHCP”
❒ When you use the IEEE 1394 in-
terface on a network, you can-
not use the Ethernet interface in
the same domain. To use both
interfaces in the same domain,
set different values for the [Sub-
net Mask].
❒ The physical address (MAC ad-
dress) also appears.
❖
❖❖
❖ IP over 1394
When you use the IP over 1394
function of the IEEE 1394 interface
to connect the machine to the net-
work, or you print from computer
with the IP over 1394 driver, you
must specify [Active]for [IP over
1394].
• Active
• Inactive
Note
❒ Default: Active
❖
❖❖
❖ WINS Configuration
You can specify the WINS server
settings.
• ON
If [ON] is selected, specify the
[WINS Server] IP address as
“xxx.xxx.xxx.xxx” (“xxx” indi-
cates a number).
If DHCP is in use, specify the
[Scope ID].
• WINS Server:000.000.000.000
• Scope ID
• OFF
