Machine configuration
Note
* (asterisk) is displayed with the current setting.
Regarding *1-*5, see table below.
*1 Input Tray: Name
*2 Input Tray: Paper Size
Item Description
Input Tray
No.
Name
Paper Size
Status
ID number of the paper tray
Name of the paper tray
*1
Paper size loaded in the paper tray
*2
Current status of the paper tray
*3
Output Tray
No.
Name
Status
ID number of the output tray
Name of the output tray
*4
Current status of the output tray
*5
Name Description
Tray X Name of installed paper tray (X is the number
of tray.)
LCT Large Capacity Tray (LCT)
Bypass Tray Bypass tray
Paper size Description
A3 (297 × 420) A3L
B4JIS (Japanese Industrial Standard) (257 ×
364)
B4L
A4 (297 × 210) A4L
A4 (210 × 297) A4K
B5JIS (257 × 182) B5L
B5JIS (182 × 257) B5K
A5 (210 × 148) A5L
A5 (148 × 210) A5K
A6 (105 × 148) A6L
11 × 17 DLTK
8
1
/
2
× 14 LGL
8
1
/
2
× 11 LTK
