Single-line Messages on the Display Panel
107
9
Single-line Messages on the Display Panel
This section describes the most common network-related messages that appear
on the display panel. If a message not described here appears, act according to
that message.
Messages without Code Numbers
Reference
Before turning the main power off, see "Turning On the Power", General Set-
tings Guide.
Message Causes Solutions
Ethernet board has a problem. An error has occurred in the
Ethernet board.
Turn off the main power
switch, and back on again. If
the message appears again,
contact your sales or service
representative.
IEEE1394 board has a prob-
lem.
An error has occurred in the
IEEE 1394 board.
Problems with IEEE1394
Board.
An error may have occurred
in the IEEE 1394 board.
HDD has a problem. An error has occurred in the
hard disk drive.
IEEE 802.11b (Wireless LAN)
has a problem.
An error has occurred in the
IEEE 802.11b (wireless LAN)
board.
Turn off the main power
switch, and check the card is
installed correctly. If the mes-
sage appears again, contact
your sales or service repre-
sentative.
Cannot connect with the wire-
less card.
IEEE 802.11b card was not in-
serted when the machine was
turned on, or it was pulled out
after the machine turned on.
An error has occurred in the
IEEE 802.11b card.
Problems with the wireless
card.
An error has occurred in the
IEEE 802.11b card.
Turn off the main power
switch, and back on again. If
the message appears again,
contact your sales or service
representative.
Problems with the wireless
board.
An error has occurred in the
IEEE 802.11b (wireless LAN)
board.
