Appendix
100
9
msh> wins
WINS Configuration:
interface_name:
WINS: On
primary server
0.0.0.0 secondary server
0.0.0.0
ScopeID
Current configura-
tion:
primary server
0.0.0.0 secondary server
0.0.0.0
hostname host_name
ScopeID
Note
❒ If the IP address obtained from
DHCP differs from the WINS IP
address, the DHCP address is
the valid address.
❖
❖❖
❖ Configuration
Use the "set" command to make
WINS active or inactive.
msh> wins interface_name
{on | off}
•“on” means active; “off” means
inactive.
❖
❖❖
❖ Setting WINS Server Address
You can make settings for the
WINS server address.
msh> wins interface_name
{primary|secondary}
IP_address
•“primary” is for setting the pri-
mary WINS server address.
•“secondary” is for setting the
secondary WINS server ad-
dress.
❖
❖❖
❖ NBT scope ID setting
You can configure the NBT scope
ID.
Limitation
❒ Enter a scope ID using up to 31
alphanumeric characters.
msh> wins interface name
scope scope ID
Note
❒ If you receive different scope
IDs from DHCP and WINS, the
scope ID from DHCP takes pri-
ority.
*1
Available when the optional
802.11b interface kit is installed.
*2
Available when the optional 1394
interface board is installed.
AutoNet
Use the "autonet" command to config-
ure AutoNet settings.
❖
❖❖
❖ Display
The following command displays
the current AutoNet settings.
msh> autonet
❖
❖❖
❖ Configuration
You can configure the AutoNet
settings.
msh> autonet interface_name
[on|off]
Note
❒ Select [on] to enable AutoNet.
❒ Select [off] to disable AutoNet.
❖
❖❖
❖ Interface Priority Configuration
You can assign priorities govern-
ing which interface obtains Au-
toNet parameters.
msh> autonet priority
interface_name
Interface name
Interface to be configured
ether Ethernet interface
wlan
*1
IEEE 802.11b interface
ip1394
*2
IEEE 1394 interface
