Using the Printer Function
54
5
Changing port settings
This describes how to change the port
settings under Windows 2000 when a
printer driver has been installed.
A
AA
A
In the [Printers] window, click the
icon of the printer you want to
use. On the [File] menu, click
[Properties].
B
BB
B
Click the [Ports] tab, and then
click [Add Port].
Select the port you want to use.
SmartNetMonitor
A Click [
SmartNetMonitor
], and then
click [
New Port
].
B Select the printer you want to
use.
❖
❖❖
❖ TCP/IP
A
Click [TCP/IP], and then
click [Search(S)].
Available printers are list-
ed.
B
Click the printer you want
to use, and then click [OK].
Note
❒ Printers that respond to a
broadcast from the com-
puter will be displayed.
To print to a printer not
listed here, click [Specify
Address(P)], and then enter
the printer's IP address or
host name.
❖
❖❖
❖ NetBEUI
Note
❒ Do not use NetBEUI un-
der Windows XP.
A
Click [NetBEUI], and then
click [Search(S)].
Available printers are listed.
B
Click the printer you want
to use, and then click [OK].
Note
❒ Printers that respond to a
broadcast from the com-
puter will be displayed.
To print to a printer not
listed here, click [Specify
Address(P)], and then enter
the NetBEUI address.
Confirm the NetBEUI ad-
dress on the network ap-
pears on the configuration
page. For more informa-
tion about printing the
configuration page, see
Printer Reference 2. Net-
BEUI addresses appear as
"\\RNPxxxx\xxx" on the
configuration page. Enter
the printer's network path
name in the format:
"%%Computer
name\Share name". Do
not enter "\\" as head
characters but "%%".
❒ You cannot print to print-
ers beyond routers.
❖
❖❖
❖ IPP
A
Click [IPP].
The IPP setting dialog box
appears.
B
To specify the IP ad-
dress of the printer,
enter "http://printer's
IP address/printer" or
"ipp://printer's IP ad-
dress/printer" in the
[Printer URL(U)] box.
(Example: IP address is
192.168.15.16)
http://192.168.15.16/
printer
ipp://192.168.15.16/p
rinter
