SG1400C3 STUDIO GENERATOR • OPERATION AND PARTS MANUAL — REV. #1 (02/15/12) — PAGE 99
HYD. VENT ACTUATOR HOSING ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 3/8SAE100R2-ATX35 HOSE, 3/8"X35" MANIFOLD to CYLINDER 2
2 6802-08-06-NWO ELBOW, 45 1/2"MJ to 3/8"MAORB 1
3 2501-06-04 ELBOW, 90
0
3/8"MJ to 1/4"NPT 2
4 EE41337 ANGLE, BRACKET 1
5 EE46266 SOLENOID VALVE, 3WAY, 24V, 3/8" PORTS 1
6 EE41837 CONN, DIN, PROPORTIONAL SOLENOID 1
7 BOLT, HEX.HD, 1/4-20 X 2" .......................................6 ............OBTAIN LOCALLY
8 WASHER, FLAT 1/4" .................................................12 ...........OBTAIN LOCALLY
9 WASHER, LOCK 1/4" ...............................................6 ............OBTAIN LOCALLY
10 NUT, 1/4-20 ................................................................6 ............OBTAIN LOCALLY
12 KTM110210 VINYL TUBING,CLEAR, 1/4X3/8X18' LONG 36
13 30-250 HOSE BARB, STEEL, 1/4"(30882-4-4B) 4
14 10-287 ELBOW, MALE 90
0
SAE 45
0
FLARE 1/4X1/4(149F-4-4) 2
15 28-248 TEE, BRASS STREET, 1/2" (2225P-8) 1
16 10-289 ELBOW, MALE 90
0
SAE 45
0
FLARE 1/4X1/2 (149F-4-8) 1
17 10-258 FITTING, BRASS MALE, 1/4X1/2 (48F-4-8) 1
18 6400-06-06-O FITTING, STRAIGHT, 3/8MJX3/8MAORB 1
