SG1400C3 STUDIO GENERATOR • OPERATION AND PARTS MANUAL — REV. #1 (02/15/12) — PAGE 109
HYD. PUMP, COOLER, FAN MOTOR AND HOSE ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 3/4SAE100R4-46 HOSE, HYD. 3/4 x 46" TANK TO PUMP 1
2 6801-12-12-NWO ELBOW, 90° 3/4"MJ x 3/4"MAORB 1
3 6801-08-10-NWO ELBOW, 90° 5/8"MAORB x 1/2"MJ 1
4 1/2SAE100R2-AT-1 HOSE, HYD. 1/2" x 17" PUMP TO FILTER 1
5 EE55927 PUMP, HYD. 0.88CU IN/REV CCW, A-FLANGE 1
6 SCREW, SOCKET HD. CAP 10MM x 30MM .............2 ............OBTAIN LOCALLY
7 WASHER, FLAT, 10MM .............................................2 ............OBTAIN LOCALLY
8 WASHER, FENDER 3/8" (CUT FLAT on ONE SIDE) ....2 ............OBTAIN LOCALLY
9 HOSE, HIMILER BLUE HEATER, ............................AR ..........OBTAIN LOCALLY
SAEJ20R3-HT-D3-EC, GOODYEAR
10 30-266 BARB, FEMALE, 37° JIC FLARE SWIVEL 3/8 x 3/8 1
11 6801-06-06-NWO ELBOW, 90°, 3/8"MJ x 3/8"MAORB 1
12 6801-08-10-NWO ELBOW, 90°, 5/8"MAORB x 1/2"MJ 1
13 1/2SAE100R2-AT-124 HOSE, HYD., 1/2" x 124" MOTOR TO COOLER 1
14 1/2SAE100R2-AT-94 HOSE, HYD., 1/2" x 94" 90°/STR. BYPASS TO COOLER 1
15 6602-08-08-08 RUN TEE, 1/2"FJS x 1/2"MJ x 1/2" MJ 1
16 6801-08-12-NWO ELBOW, 90°, 1/2"MJ x 3/4"MAORB 1
17 1/2SAE100R2-AT-170 HOSE, HYD., 1/2" x 170" COOLER TO TANK 1
18 6801-08-12-NWO ELBOW, 90°, 3/4"MAORB x 1/2"MJ 1
19 1/2SAE100R2-AT-94 HOSE, HYD., 1/2" X 94" FILTER TO MOTOR 1
20 3/8SAE100R2-AT-48 HOSE, HYD., 3/8" x 48" MOTOR TO MANIFOLD 1
21 6801-08-08-NWO ELBOW, 90°, 1/2"MJ x 1/2" MAORB 1
22 6801-06-08-NWO ELBOW, 90°, 3/8"MJ x 1/2"MORB 1
23 6835-08-08-08-NWO TEE, RUN, 1/2"FORM x 1/2"FORM x 1/2"FORB x 1/2"MAORB 1
24 EE41126 TEST FITTING, PRESSURE GUAGE 1
25 6410-08-04-O FITTING, STRAIGHT, 1/2"MORB x 1/4"FORB 1
26 6835-08-08-08-NWO TEE, RUN, 1/2"FORB x 1/2"FORB x 1/2"FORB x 1/2"MAORB 1
27 6410-10-08-O FITTING, STRAIGHT, 1/2"FORB x 5/8"MORB 1
