SG1400C3 STUDIO GENERATOR • OPERATION AND PARTS MANUAL — REV. #1 (02/15/12) — PAGE 107
NO. PART NO. PART NAME QTY. REMARKS
26 EE42719 SPACER, 1/2"OD x 1/4"ID x 3/4" LG, ZINC PLT 2
27 EE55034 Z-BRACKET, HYD FILTER W/QSB7 1
28 WASHER (COMES WITH ENGINE) 2
29 NUT (COMES WITH ENGINE) 2
30 1/2SAE100R2-AT-94 HOSE,HYD. 1/2" x 94" FILTER TO MOTOR 1
31 6801-08-08-NWO ELBOW, 90deg. 1/2 MAORB x 1/2 MJ 1
32 3832-08-08-08NWO TEE, BRANCH, 1/2MAORB x 1/2FORB x 1/2FORB 1
33 6410-12-08-O FITTING, STRAIGHT, 3/4MORB x 1/2FORB 1
34 3474-08-08-NWO FITTING, STRAIGHT, 1/2MAORB x 1/2MORB 1
35 EE42147 PROPORTIONAL RELIEF VALVE W/BODY, 3000PSI 1
36 6802-08-08-NWO ELBOW, 45°, 1/2MAORB x 1/2MJ 1
37 1/2SAE100R2-AT-94 HOSE, HYD., 1/2" x 94" BYPASS TO COOLER 1
38 7045-08-22 METRIC ADAPTER, 1/2 FP x 22MM x 1.5MM 1
39 5500-8 ELBOW, 90°., MALE PIPE 1
40 EE18072 VALVE, LOCKING BALL, BRASS, 1/2" FNPT 1
41 10-273 FITTING, MALE ADAPTER,SAE 45° FLARE 5/8 x 1/2 2
42 30-258 BARB, 45° SAE FLARE FEMALE SWIVEL, 5/8 x 5/8 4
43 HOSE, 5/8" INSTAGRIP 300PSI WP ............................ AR ................ OBTAIN LOCALLY
FLAME RESISTANT
USMSHA2G-1C-14C/33 GOODYEAR
44 10-303 ELBOW, 90° MALE, 5/8" x1/2" 2
45 28-027 TEE, UNION, 1/2 NPTR 1
46 207ACBH-8 COUPLING, BULKHEAD, W/STAR WSH & NUT 1
HYD. TANK, FILTER AND HOSE ASSY.
