SG1400C3 STUDIO GENERATOR • OPERATION AND PARTS MANUAL — REV. #1 (02/15/12) — PAGE 77
CONTROL BOX ASSY. (INTERIOR)
NO. PART NO. PART NAME QTY. REMARKS
1 EE55789 BOX, INTELLIGEN CONTROL 1
2 EE41835 SX MICRO-CONTROL, CAN, BUS, HYD CTRL 1
3 EE45116 CONN, DEUTCH 9-PIN, ROUND 1
4 EE26112 BLOCK, TERMINAL, SAK, 4-WEIDMULLER 40
5 EE26107 END PLATE, TERM, SAK, 4-WEIDMULLER 1
6 EE26106 PARTITION, WEIDMULLER 4
7 EE10618 SWITCH, 15 MIN. TIMER W/ SCREWS 1
8 EE10071 RAILDIN, ALUM, .413"X1.37"X36" 1
9 EE26385 BASE, RELAY, SNAP/SURFACE MTG 8-BLADE 3
9A EE23861 RELAY, MINIATURE, 8-BLADE 3
9B EE26135 RETAINER, HLD DOWN WIRE FOR RLY 8-BLADE 3
10 EE2998 BASE, DIN RAIL SNAP MTG, 5H SERIES, 5-BLADE 4
10A EE47964 RELAY, MINIATURE, 5-BLADE 4
10B EE3015 RETAINER, RELAY HOLDDOWN, IDEC MIDGET 4
11 EE55870 TRANSFORMER 120V, COMAP 16-AVRI TRANS 100 1
12 EE55810 RECEPTACLE, DEUTCH 24-PIN 1
12A EE55811 GASKET, DEUTCH RECEPTACLE 24-PIN 1
13 EE55793 RECEPTACLE, DEUTCH 40-PIN 1
13A EE55794 GASKET, DEUTCH RECEPTACLE 40-PIN 1
14 EE40238 MODULE, VOLT REG CTRL INTELLIGEN 1
15 SCREW,TRUSS HD, 6/32"X1/2", SS .........................8 ............OBTAIN LOCALLY
15A NUT, NYLOC, 6/32", SS .............................................4 ............OBTAIN LOCALLY
16 SCREW, TRUSS HD, 8/32"X5/8", SS ........................8 ............OBTAIN LOCALLY
16A NUT, NYLOC, 10/32", SS ...........................................8 ............OBTAIN LOCALLY
17 SCREW, PN HD, 1/4-20 X 2 1/4", SS ........................2 ............OBTAIN LOCALLY
18 EE2940 END STOP, DIN RAIL, SQ DC1A W/ SCREW 4
19 EE41836 CONN KIT, SX MICRO-CONTROL, 18-CONTACT 1
20 EE42034 CONN KIT, SX MICRO-CONTROL, 3-CONTACT 1
FAN CONTROL PROGRAMMING CONNECTOR)
21 EE37735 PIN, SOLID, GOLD-PLATED, 16 51
22 EE37935 PLUG, SEAL, DEUTCH 12-16 SOCKETS 27
23 EE32611 JUMPER, 3-POLE SAK 4-WEIDMULLER 9
24 EE36833 SOCKET, SOLID, GOLD CONTACT 51
25 EE55812 PLUG, DEUTCH 24 SOCKET 1
26 EE41693 CONN, RECTANG, 40 SOCKET, SZ16 1
27 EE55813 BOOT, DEUTCH, DRC26-24 BT 1
28 EE55788 BOOT, DEUTCH, DRC26-40 BT 1
