SG1400C3 STUDIO GENERATOR • OPERATION AND PARTS MANUAL — REV. #1 (02/15/12) — PAGE 71
HOUSING (INTERIOR) ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 EE55742 HOUSING, 1400 A STUDIO, SINGLE BUS DOOR 1
2 844402-9 DOOR ASSY, LEFT SIDE 3
3 279-1 HANDLE, DOOR ASSY 7
4 PH110ZN LATCH, DOOR HANDLE, 2-POINT 6
5 EE55742-1 DOOR ASSY, CAMLOK 1
6 2101-L LEFT HANDLE, DOOR ASSY 2
7 87403 ASSY DOOR ASSY, RAIN DOOR 1
8 107084-2 EXHAUST VENT DOOR ASSY 1
9 107084-1 INTAKE VENT DOOR ASSY 1
10 EE55742-18 DOOR ASSY, CONTROL PANEL ..............................1 ............INCLUDES ITEMS W/
*
11
*
EE55742-18-2 PLEXIGLASS WINDOW 1
11A
*
AS-1522 GASKET, PLEXIGLASS WINDOW 1
12
*
EE55742-18-1 DOOR, CONTROL PANEL 1
13 EE55742-18-3 BRACKET, DOOR PROP 1
14 EE55742-18-4 DOOR PROP 1
15 R241542-KEYIL101 LATCH, LOCKING 1
16 84402-11 ASSY DOOR ASSY, FRONT 1
17 PH108ZN LATCH, DOOR HANDLE, 3-POINT 1
18 84402-8 ASSY DOOR ASSY, RIGHT SIDE 2
19 84402-25 DOOR ASSY, RIGHT SIDE, FRONT 1
20 9416K1720 GAS SPRING, 20 LB 2
21 EE26562 BALL STUD, GAS SPRING, 10 MM STEEL 2
22 9416K74 BALL SOCKET, 10 MM STEEL 4
23 EE7745 BRACKET, EXTERIOR LIGHTS 4
24 EE26552 LIGHT, OVAL, 24 V 4
25 EE26313 GROMMET, EXTERIOR LIGHTS 4
26 EE23297 MANUAL HOLDER 1
27 EE55742-18-5 BRACKET, DOOR LATCH 1
28 EE7379 BRACKET RETAINER/DOOR STOP 1
29 EE7490 ASSY, STRAP ANCHOR DOOR RESTRAINT 1
30 EE21973 GUIDE, 7/16", SS 1
31 EE10244 STOP, DOOR CHAIN, 30" 1
32 EE10644 SWITCH, OMRON, ENCLOSED LIMIT 1
33 97440-1 ASSY SWINGING SKIRT ASSY, RT 1
34 87440-2 ASSY SWINGING SKIRT ASSY, LT 1
35 EE39267 ASSY, FLANGE AND NIPPLE 6" LOW PRO. 1
36 EE39269 RAIN CAP, ASSY 1
37 EE26975 HOOK, OPEN END TYPE 304SS 1
38 EE7663 SPOILER, VENT DOOR PROTECTOR 1
39 EE22204 RAIN GUTTER, J-STRIP, BLY FIN. ..........................AR ..........1 PC=1 FT
40 EE16554 LAMP, RUBBER HSG 24VDC W/ MTG. HDWR. ........1 ............INCLUDES ITEM W/ #
41# BOLT, 3/8-16 X 2 3/4, SS ...........................................1 ............OBTAIN LOCALLY
42# NUT, NYLOC 3/8-16 ..................................................2 ............OBTAIN LOCALLY
43 EE55766 HEAT SHIELD 6", RAINCAP 16 GA. SS 1
44 EE55790 HAT SECTION, VENT DOORS 2
