SG1400C3 STUDIO GENERATOR • OPERATION AND PARTS MANUAL — REV. #1 (02/15/12) — PAGE 69
HOUSING (BASE) ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 EE55742 HOUSING, 1400 STUDIO, SINGLE BUS DOOR 1
2 EE40474 BASE, 1400A STUDIO, 48" X 100" 1
3 INSULATION ..............................................................1 ............SEE NOTICE BELOW
4 PLYWOOD .................................................................1 ............SEE NOTICE BELOW
5 PLYWOOD .................................................................1 ............SEE NOTICE BELOW
6 EE6653 BRACKET, STEP BAFFLE, MTG TO HSG 2
7 WASHER, COMM 3/8" ...............................................4 ............OBTAIN LOCALLY
8 WASHER, LOCK 3/8" ................................................4 ............OBTAIN LOCALLY
9 NUT, 3/8-16 ................................................................4 ............OBTAIN LOCALLY
10 EE33397 ASSY, STEP BAFFLE WITH INSULATION 1
NOTICE
For repair of the base, unit needs to be returned to
the MQ Service Department in Carson, CA. Contact
Telephone No. 800-421-1244..
