SG1400C3 STUDIO GENERATOR • OPERATION AND PARTS MANUAL — REV. #1 (02/15/12) — PAGE 73
CAMLOK ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 EE55746 PANEL, OUTPUT BUS, CAMLOK 1
2 EE6378 RECEPTACLE, PNL MTG, FEMALE BLACK 6
3 EE6381 RECEPTACLE, PNL MTG, FEMALE BLUE 6
4 EE6380 RECEPTACLE, PNL MTG, FEMALE RED 6
5 EE6379 RECEPTACLE, PNL MTG, FEMALE WHITE 6
6 EE6382 RECEPTACLE, PNL MTG, FEMALE GREEN 5
7 EE6387 RECEPTACLE, PNL MTG, MALE GREEN 1
8 EE55776 BUS BAR, 6 SET CAMLOK, 3" SPACING 5
9 EE34475 BUS BAR, GROUND TO NEUTRAL 1
10 EE6129 RECEPTACLE, FLANGED, PHILLIP/SLOT SCREW 2
10A SCREW, PHILLIPS, RDHD, 8/32"X3/4, SS ...............4 ............OBTAIN LOCALLY
11 EE40182 BATES CONN, 100A, 125V, FEMALE 2
11A SCREW, PHILLIPS, FH COUNTERSUNK, 1/4-20X1 3/4, SS ..4 ............OBTAIN LOCALLY
12 EE22728 LED, PILOT LIGHT, RED 270V, LEDTRONIC 1
13 EE55760 JACK, FEEDTHROUGH, RJ45, CAT5E 5HD 2
14 EE55791 CB, HEIN, 15A, 1 POLE, UL489, 240V 2
14A SCREW, PHILLIPS, TRUSS HD, 5/32" X 5/8", SS.....8 ............OBTAIN LOCALLY
15 EE55869 CB, HEIN, 100A, 1 P, UL489, 240V, W/ 24V SHUNT 2
16 EE25626 JACK, BANANA PLUG, 4 MM IEC1010, BLACK 1
17 EE25628 JACK, BANANA PLUG, 4 MM IEC1010, BLUE 1
18 EE25627 JACK, BANANA PLUG, 4 MM IEC1010, RED 1
19 EE25625 JACK, BANANA PLUG, 4 MM IEC1010, WHITE 2
20 EE55777 COVER, RECEPTACLE EXPANSION, W/ MQ LOGO 1
21 SCREW, PHIL PAN HD, #10X3/4, SS ......................120 ..........OBTAIN LOCALLY
22 WASHER, FLAT 1/2", BRASS ..................................30 ...........OBTAIN LOCALLY
23 WASHER, SPLIT LOCK 1/2", BRASS ......................30 ...........OBTAIN LOCALLY
24 NUT, FINISHED HEX. HD, 1/2-13, BRASS ...............30 ...........OBTAIN LOCALLY
25 WIRE WITH TERMINAL ............................................5 ............MAKE LOCALLY
26 EE2889 CONN, FEMALE SOCKET, MIL SPEC 20-PIN 1
26A SCREW, PHIL TRUSS HD, 6/32X1/2, SS ..................4 ............OBTAIN LOCALLY
27 EE2880 CAP, PROTECTIVE, MS RECEPTACLE 1
28 EE55780 CABLE, ETHERNET CAT5E SHIELDED, 50 FT 1
29 EE55871 CONVERTER, COMAP NT TO LEGACY PAR'L 1
30 SCREW, PHIL TRUSS HD, 6/32X5/8, SS ..................2 ............OBTAIN LOCALLY
30A NUT, 6/32 NYLOC ......................................................2 ............OBTAIN LOCALLY
31 EE10071 RAIL, DIN ALUM .413"X1.37"X6" 1
32 EE2940 END STOP, DIN RAIL, SDCIA 2
33 EE55859 LEXAN COVER, OUTPUT BUS' 2
34 EE6449 STICKER, DANGER HIGH VOLTAGE 2
35 EE15770 STANDOFF, HEX STYLE, ALUM 3" 2
36 EE51414 PLACARD, VINYL, ADHESIVE, ARC FLASH 7
37 BOLT, HEX HD, 1/4-20 X 3/4 SS ................................6 ............OBTAIN LOCALLY
38 WASHER, LOCK 1/4" SS ..........................................6 ............OBTAIN LOCALLY
39 WASHER, FLAT 1/4" SS ............................................6 ............OBTAIN LOCALLY
