SG1400C3 STUDIO GENERATOR • OPERATION AND PARTS MANUAL — REV. #1 (02/15/12) — PAGE 93
ENGINE STARTER, RELAY AND BATTERY ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 EE55818 PANEL, STARTER RELAY 1
2 EE2923 RELAY, BOSCH 24V 2
3 EE2917 RELAY, STARTER SOLENOID 24V 1
4 EE10881 BREAKER, CIRCUIT, PUSHBUTTON 30A 1
5 EE10878 BREAKER, CIRCUIT, PUSHBUTTON 15A 2
6 EE9983 TRACK, FLEXIBLOCK, TERMINAL STRIP 1
7 EE9954 BLOCK, BLUE FLEXI TERMINAL #6 18
8 EE9985 STOP, BLUE FLEXI BLOCK, TERMINAL 2
9 EE55839 SPACER, 1/2" IDXI", ALUM 2
10 EE55840 STANDOFF, 1/4-20 X 1" 2
11 EE11875 BATTERY, AUTO, GROUP-27 CENTENNIAL 2
12 EE7752 TRAY, BATTERY, 27-60, SS 1
13 EE7791 BRACKET, HOLD DOWN ANGLE 1
14 EE34486 J-BOLT, BATTERY, 10.38" LONG 2
15 NUT, ACORN CAP, 5/16-18, SS ................................2 ............OBTAIN LOCALLY
16 NUT, NYLOCK 55, 5/16-18, SS .................................2 ............OBTAIN LOCALLY
17 EE40908 WASHER, SNUBBING, 2.0" OD, .45" I.D. 2
18 BOLT, HEX HD, 3/8-16 X 1 1/4" .................................8 ............OBTAIN LOCALLY
19 WASHER, LOCK, 3/8" ...............................................8 ............OBTAIN LOCALLY
20 WASHER, FLAT, 3/8" .................................................8 ............OBTAIN LOCALLY
21 SPRING NUT, 3/8-16, U-CHANNEL ..........................8 ............OBTAIN LOCALLY
22 EE22005 CABLE, WELDING, 5225/34 STRAND 9" ................9" ...........1 PC = 1 FT
23 EE22005 CABLE, WELDING, 5225/34 STRAND 28" .............28" ..........1 PC = 1 FT
24 EE22005 CABLE, WELDING, 5225/34 STRAND 34" .............34" ..........1 PC = 1 FT
25 EE23247 BOOT COVER, TERMINAL, POSITIVE "RED" 2
26 EE23248 BOOT COVER, TERMINAL, NEGATIVE "BLACK" 2
27 EE5758 HOLDER, FUSE, IN-LINE 1
27A EE5788 FUSE, BUSS, AGC, 10A 1
28 NUT ............................................................................2 ............OBTAIN LOCALLY
29 WASHER ...................................................................2 ............OBTAIN LOCALLY
30 BOLT, HEX HD, 12MM-1075 X 50 MM ......................2 ............OBTAIN LOCALLY
31 WASHER, LOCK, 12MM............................................2 ............OBTAIN LOCALLY
32 WASHER, FLAT, 12MM .............................................2 ............OBTAIN LOCALLY
33 SCREW, PHIL PAN HD, #10-32 X 1/2" ......................3 ............OBTAIN LOCALLY
34 WASHER, FLAT, #10 .................................................3 ............OBTAIN LOCALLY
35 SCREW, TRUSS, PHIL HD, #6-32 X 3/8" ..................4 ............OBTAIN LOCALLY
37 EE43186 HEAT SHIELD 1
38 BOLT, HEX HD, 1/4-20 X 5/8" ....................................2 ............OBTAIN LOCALLY
39 WASHER, LOCK 1/4" ................................................2 ............OBTAIN LOCALLY
40 WASHER, FLAT 1/4" ..................................................2 ............OBTAIN LOCALLY
41 BOLT, HEX HD, 10 MM X 1 1/4" ................................2 ............OBTAIN LOCALLY
42 WASHER, LOCK, 10 MM...........................................2 ............OBTAIN LOCALLY
43 WASHER, FLAT, 10 MM ............................................2 ............OBTAIN LOCALLY
