SG1400C3 STUDIO GENERATOR • OPERATION AND PARTS MANUAL — REV. #1 (02/15/12) — PAGE 81
RADIATOR/MUFFLER SUPPORT
NO. PART NO. PART NAME QTY. REMARKS
1 EE41013 SUPPORT, RADIATOR 1
2 EE25484 COVER, FAN, STEEL 1
3 EE41023 ASSY, ARC BAFFEL W/ INSULATION 1
4 EE41698 VENTURI RING, 30" REVERSE CONSTR. 1
5 EE32785 UNISTRUT CHANNEL, MFL SUPPORT 2
6 EE42003 SUPPORT, MUFFLER 1
7 EE46381 HAT SECTION, EXH VENT, HYD. ACTUATOR 1
8 EE55759 MOUNTING PLATE, 16" CYL. SILENCER 2
9 EE7363 MOUNTING BRACKET, MUFFLER SUPPORT 2
10 EE42004 DIAGONAL SUPPORT, 45˚, RIGHT 1
10A EE42005 DIAGONAL SUPPORT, 45˚, LEFT 1
11 EE43047 MOUNTING PLATE, BAFFLE 2
12 EE55771 BAFFLE, 28" X 21.5" X 2" THICK, ALUM. 1
13 BOLT, HXHD 3/8-16 X 1 3/4" ...................................AR ..........OBTAIN LOCALLY
14 LOCK WASHER, 3/8" ...............................................2 ...........OBTAIN LOCALLY
15 WASHER, FLAT 3/8" SAE .......................................AR ..........OBTAIN LOCALLY
16 EE42987 FLASHING, ALUM RAD. (SPACER) AR
17 BOLT, HX. HD. 3/8-16 X 1 1/4" .................................AR ..........OBTAIN LOCALLY
18 NUT, 3/8-16 .............................................................AR ..........OBTAIN LOCALLY
19 BOLT, HX. HD. 1/4-20 X 1" .........................................4 ............OBTAIN LOCALLY
20 WASHER, FLAT, 1/4" SAE .........................................8 ............OBTAIN LOCALLY
21 NUT, NYLOK 1/4-20 ...................................................4 ............OBTAIN LOCALLY
22 EE16554 LAMP, RUBBER HSG, 24 VDC W/ MTG. HDWR .......2 ............INCLUDES ITEMS W/
*
23
*
BOLT, 3/8-16 X 2 3/4", SS .........................................2 ............OBTAIN LOCALLY
24 WASHER, FLAT, 3/8" .................................................2 ............OBTAIN LOCALLY
25
*
NUT, NYLOCK, 3/8-16 ...............................................2 ............OBTAIN LOCALLY
