SG1400C3 STUDIO GENERATOR • OPERATION AND PARTS MANUAL — REV. #1 (02/15/12) — PAGE 91
SADDLE BOX ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 B-528258 REGULATOR, VOLTAGE, DVR2000E 1
2 A-66377-45 CAPACITOR, 7.5 MFD 1
3 EE7330 DECAL, CAUTION, DO NOT SWITCH 1
4 EE55779 TRANSFORMER, 3 KVA 1
5 EE2767 SWITCH, K+ N, VOLTAGE SELECT 3-POS 1
6 EE7392 BRACKET, MTG SWITCH TO SADDLE BOX 1
7 EE2996 CONTACTOR, 24 VDC, 4P, 600V, 30A 2
8 EE5816 BUSS FUSE BLOCK HOLDER 1
9 EE5804 FUSE, GOULD SHAWMUT, MIDGET, 10A 4
10 EE5810 FUSE, GOULD SHAWMUT, MIDGET, 30/50A 2
11 EE9954 BLOCK, BLUE FLEXI TERMINAL #6 40
12 EE9985 STOP, BLUE FLEXI BLOCK, TERMINAL 3
13 EE9983 TRACK, FLEXI BLOCK, TERMINAL STRIP 2
14 EE24222 CONTACTOR, VACCUM, 120 VAC 1
15 B-525528F RECTIFIER ASSY 1
16 EE24369 CIRCUIT BREAKER, 600A, 3P
W/ SHUNT + AUX SW. 1
17 EE55785 SWITCH, AUX, ABB 2
18 EE55784 CIRCUIT BREAKER, ABB, 3P, 10A, UL@480V 2
19 EE34388 SPACER, BRASS, CIRCUIT BREAKER 3
20 EE30075 SPACER, CIRCUIT BREAKER 1
21 EE55787 PANEL, CIRCUITBREAKER, 2 SENSING 1
22 BOLT, HXHD, 3/8-16 X 1 1/4"...................................AR ..........OBTAIN LOCALLY
23 WASHER, FLAT 3/8" ................................................AR ..........OBTAIN LOCALLY
24 NUT, NYLOC, 3/8" ...................................................AR ..........OBTAIN LOCALLY
25 BOLT, HXHD, 3/8-16 X 1"...........................................4 ............OBTAIN LOCALLY
26 WASHER, LOCK 3/8..................................................8 ............OBTAIN LOCALLY
27 NUT, 3/8-16 ................................................................8 ............OBTAIN LOCALLY
28 EE10479 TRANSFORMER, CURRENT, 1000:5 3
