SG1400C3 STUDIO GENERATOR • OPERATION AND PARTS MANUAL — REV. #1 (02/15/12) — PAGE 113
NO. PART NO. PART NAME QTY. REMARKS
1 EE36264 PINTLE, EYE, RING 3" 1
2 EE42617 CAP SCREW, HX. HD. GRD 8 2
3 EE35394 WASHER, FLAT ZINC PLT. 5/8" 4
4 EE42618 NUT, HX. NYLOCK-INSERT, GRD 8 2
5 EE55941 ACTUATOR, HYDR SURGE BRK 20K 1
6 EE16523 JACK, BULLDOG, SQ. TUBE 1
7 EE23172 HOOK, CHAIN 2
8 EE23173 CHAIN, TRANSPORT TRLR, 3/8" .....................1................1PC=10FT
9 EE23276 CARRIER, SPARE TIRE 1
10 EE42512 TOOL BOX COVER, TANDEM AXLE 1
11 EE37210 TANK, FUEL, 150 GAL. SGL WALL 1
12 EE23182 FENDER, 12", STUDIO TANDEM AXLE 2
13 EE43001 PLATE, TREAD BRITE, FENDER TOP 2
14 EE47139 CHROME BEZEL, 2-1/2" W/O VISOR 6
15 EE43535 LIGHT, AMBER, 2-1/2" CLEARANCE/SIDE 2
16 EE47063 KIT LIGHT, MARKER, RED 4
17 EE2926 LIGHT, UTILITY, MULTI-PURPOSE 2
18 EE47138 LIGHT GUARD, STAINLESS STEEL 3
19 EE47137 LIGHT, CLEARANCE MARKER, RED 3
20 EE23183 BUMPER, RUBBER 2
21 EE47141 CROME BEZEL, 4", W/O VISOR 4
22 EE55450 KIT LIGHT, STOP/TURN/TAIL, 4" RED 4
23 EE16547 LIGHT, RED RUNNING, WARNING 2
24 EE16549 LIGHT, AMBER RUNNING, WARNING 2
25 EE36960 AXLE, TANDEM, ELEC. BRK. 2
26 EE38731 TIRE, 16" GOODYEAR W/STEMS 5
27 EE38730 WHEEL RIM, 16" CHROME 5
28 EE48199 LUG NUT, 1/2-20 CHROME 32
29 EE38732 WHEEL & TIRE, 16" CHROME 5
30 EE43005 PLATE, TREAD BRITE, FENDER STEP 4
TRAILER ASSY.
