SG1400C3 STUDIO GENERATOR • OPERATION AND PARTS MANUAL — REV. #1 (02/15/12) — PAGE 83
RADIATOR/FAN ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 EE41227 RADIATOR, ALUM 1
2 EE38918 OVERFLOW BOTTLE, RAD COOLANT 1
3 EE43735 BRACKET, OVERFLOW BOTTLE 1
4 EE41285 MNTG PLATE, CHARGE AIR COOLER 2
5 EE40443 CHARGE, AIR COOLER 1
6 EE42213 HEAT EXCHANGER, OIL/AIR, COIL 1
7 EE42208 BRACKET, OIL COOLER 1
8 SCREW, CAP, SOCKET HD. 8/32 X 1/2 ...................16 ...........OBTAIN LOCALLY
9 EE46381 HAT SECTION, EXHAUST VENT HYD ACT. 1
10 NUT, 1/4-20" ..............................................................2 ............OBTAIN LOCALLY
11 EE46373 HYDRAULIC CYLINDER, 1 1/2" X 10" STROKE 2
12 EE7079 SPRING, EXT., .072" DIA X 16" LG, SS 4
13 EE41809 SHIM, .063", BRACKET, HYD. MOTOR 4
14 EE41081 BRACKET, HYD MOTOR 1
15 EE42215 MOTOR, HYD 1
16 EE42568 FAN, 30", 9 BLADE, 40˚ 1
17 EE42988 WASHER, SAFETY, HYDRAULIC FAN 1
18 EE45521 SEAL, PACKARD CONN 3
19 EE45520 TERMINAL, FEMALE, PACKARD CONN 3
20 EE45518 CONN BODY, 3 TERMINAL, PACKARD 1
21 EE45026 SENSOR, COOLANT LEVEL, 3 PIN 1
22 EE45519 TPA LOCK, 3 TERMINAL PACKARD CONN 1
23 EE26294 BOLT, HEX HD, 3/8-16 X 4
24 WASHER, FLAT 3/8" .................................................22 ...........OBTAIN LOCALLY
25 NUT, NYLOC THIN, 3/8-16 ........................................4 ............OBTAIN LOCALLY
26 SCREW CAP, FLAT SOCKET HD, 3/8-16 X 1" ..........2 ............OBTAIN LOCALLY
27 NUT, NYLOC, 3/8-16 .................................................4 ............OBTAIN LOCALLY
28 BOLT, HX HD, 3/8-16 X 1 1/2 .....................................6 ............OBTAIN LOCALLY
29 WASHER, LOCK 3/8" ...............................................6 ............OBTAIN LOCALLY
30 BOLT, HX HD, 1/4-20 X 3/4 .......................................10 ...........OBTAIN LOCALLY
31 WASHER, LOCK 1/4" ...............................................10 ...........OBTAIN LOCALLY
32 WASHER, FLAT 1/4" .................................................12 ...........OBTAIN LOCALLY
