TDB3108, WF3208 Terreon
®
54" Circular Installation
4 4/6/2007 Bradley Corporation • 215-1187 Rev. N; EN 06-915B
Circular Washfountain Dimensions (TAS intermediate)
61"
(1549)
WITH
SOAP
52-1/2"
(1334)
WITHOUT
SOAP
54"
(1372)
35-1/2"
(902)
19-1/2"
(495)
53-1/4"
(1353)
44-5/8"
(1143)
41-1/8"
(1045)
32"
(813)
25-1/2"
(648)
12"
(305)
6" (152)
Adjust to towel dispenser
mounting holes
TAS
54"
(1372)
19-1/2"
(495)
35-1/2"
(902)
25-1/2"
(648)
12"
(305)
32"
(813)
41-1/8"
(1045)
44-5/8"
(1133)
Model TDB3108
54" Circular - TAS Height
Model TDB3108
54" Circular - TAS Height with
optional accessories
Figure 1c
Figure 1d
Optional equipment may not comply with
all TAS dimensional guidelines
