TDB3108, WF3208 Terreon
®
54" Circular Installation
2 4/6/2007 Bradley Corporation • 215-1187 Rev. N; EN 06-915B
Table of Contents
Pre-Installation Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Model TDB3108 Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
Model WF3208 Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Washfountain Rough-Ins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-8
Installation Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-19
Terreon® Cleaning/Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Gel-Coated Fiberglass Cleaning/Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Stainless Steel Cleaning/Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Soap Dispensing Valve Repair Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22-23
Soap Recommendations and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Sprayhead Troubleshooting/Repair Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Manual Mixing Valve (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Volume Control Valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Vernatherm™ Thermostatic Mixing Valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28-29
Supplies Required by Installer
• (4) 1/2" lag bolts, screws or other fasteners to anchor washfountain pedestal
• 1" hot and cold water supply lines and fittings (refer to rough-ins on pages 7-8)
• Reducing fittings and 1/2" nom. copper tubing supply lines for types with supplies from above
• Standard P-trap (refer to rough-ins on pages 7-8) (vented trap supplied by Bradley when required)
• 2" drain lines and fittings (refer to rough-ins on pages 7-8)
• 1-1/2" vent or tie pipe on fixtures vented through washfountain column (see page 9 for lengths required)
• Teflon tape or pipe dope
• 110 VAC GFI power source for 110/24 VAC UL Class II transformer supplied
• OPTIONAL: Bradley recommends installing an electrical cut-off switch to the unit. This feature
allows no accidental water delivery during regular maintenance and service.
Pre-Installation Information
Terreon
®
Material
The Washfountain is constructed of Terreon
®
, a densified solid surface material composed of polyester
resin. Terreon
®
is resistant to chemicals, stains, burns and impact. Surface damage can be easily
repaired with everyday cleaners or fine-grit abrasives. Terreon
®
is NAHB certified to meet ANSI
Z124.3, Z124.6 and ANSI/ICPA SS-1-2001.
Adaptive Infrared
The sprayhead is controlled by a solenoid valve, allowing the user to activate a flow of water. The
Infrared sensor will take a few minutes to adapt to its environment when the unit is powered up.
