E6581090
L-4
12
12.2 External dimensions/weights
■External dimensions/weights
Dimensions (mm)
Input voltage
Applicable
motor (kW)
Type
WHDW1H1D1
Drawing
Approx.
weight (kg)
0.2 VFNC1S-2002P 100 1.0
0.4 VFNC1S-2004P 124 1.0
0.75 VFNC1S-2007P
72
137
60 A
1.0
1.5 VFNC1S-2015P 1.5
1-phase 200V
(Standard)
2.2 VFNC1S-2022P
117 155 106 B
1.5
0.1 VFNC1-2001P 1.0
0.2 VFNC1-2002P
100
1.0
0.4 VFNC1-2004P 124 1.0
0.75 VFNC1-2007P
72
137
60 A
1.0
1.5 VFNC1-2015P 1.5
3-phase 200V
2.2 VFNC1-2022P
117 155 106 B
1.5
0.1 VFNC1S-1001P 1.0
0.2 VFNC1S-1002P
100
1.0
0.4 VFNC1S-1004P
72
124
60 A
1.0
1-phase 100V
0.75 VFNC1S-1007P 117 155 106 B 1.5
0.2 VFNC1S-2002PL 100 1.0
0.4 VFNC1S-2004PL 124 1.0
0.75 VFNC1S-2007PL
72
137
60 A
1.0
1.5 VFNC1S-2015PL 1.5
1-phase 200V
(Europe)
2.2 VFNC1S-2022PL
117
142
155 106
131 8.5
B
1.5
■External dimensions
D
D1
H1(Installation dimension)
H
W
φ
5
R2.5
W1
(
Installation
dimension)
Fig. A
D
D1
φ
5
H1
(
Installation dimension
)
H
W
R2.5
W1
(
Installation dimension
)
Fig. B
