E6581090
J-2
10
■Selection of wiring devices
Non-fuse circuit breaker (MCCB)
Earth leakage breaker (ELCB)
Magnetic contactor
(MC)
Overload relay
(THR)
Without reactor With DC reactor Without reactor With DC reactor
Voltage
class
Capacity of
applicable
motor
(kW)
Inverter model
Rated
current
(A)
Type
MCCB /
(ELCB)
Note1)
Rated
current
(A)
Type
MCCB /
(ELCB)
Note1)
Rated
current
(A)
Type
Note1)
Rated
current
(A)
Type
Note1)
Adjusted
current
(A)
(For reference)
Type
Note1)
0.1 VFNC1S-1001P 5 --- --- 9 --- --- 0.7 LR3D056
0.2 VFNC1S-1002P 10 --- --- 9 --- --- 1.3 LR3D066
0.4 VFNC1S-1004P 15 --- --- 9
LC1D096
--- --- 2.3LR3D076
Single-
phase
100V
class
0.75 VFNC1S-1007P 30
NJ30E
(NJV30E)
--- --- 18 LC1D186 --- --- 3.6 LR3D086
0.2 VFNC1S-2002P(L) 5 5 9 9 1.3 LR3D066
0.4 VFNC1S-2004P(L) 10 5 9 9 2.3 LR3D076
0.75 VFNC1S-2007P(L) 15 10 9
LC1D096
9
LC1D096
3.6 LR3D086
1.5 VFNC1S-2015P(L) 20 15 18 LC1D186 12 LC1D126 6.8 LR3D126
Single-
phase
200V
class
2.2 VFNC1S-2022P(L) 30
NJ30E
(NJV30E)
30
NJ30E
(NJV30E)
25 LC1D256 18 LC1D186 9.3 LR3D146
0.1 VFNC1-2001P 5 5 9 9 0.7 LR3D056
0.2 VFNC1-2002P 5 5 9 9 1.3 LR3D066
0.4 VFNC1-2004P 5 5 9 9 2.3 LR3D076
0.75 VFNC1-2007P 10 5 9 9 3.6 LR3D086
1.5 VFNC1-2015P 15 10 9
LC1D096
9
LC1D096
6.8 LR3D126
Three-
phase
200V
class
2.2 VFNC1-2022P 20
NJ30E
(NJV30E)
15
NJ30E
(NJV30E)
12 LC1D126 12 LC1D126 9.3 LR3D146
Note 1:Produced by Toshiba Schneider Electric Ltd.
Note 2:Be sure to attach a surge killer to the exciting coil of the relay and the magnetic contactor.
Selection of surge killers for Toshiba magnetic contactors
200V class: Surge absorbing units are optionally available for Toshiba C11J to C20J
Note 3:When using the auxiliary contacts 2a of the magnetic contactor MC for the control circuit, connect the
contacts 2a in parallel to increase reliability.
Of the wiring devices listed in the above table, the magnetic contactors (MC) and the overload relays (Th-Ry)
are intended for use with the Mighty J series. When using the old series (ESPER Mighty series), refer to the
table below showing the correspondence between the two series.
Magnetic contactor (MC) Overload relay
ESPER Mighty series Mighty J series ESPER Mighty series Mighty J series
C12A C13J T11A T13J
C20A C20J
