E6581090
K-9
11
■Table of input terminal functions 1
Function
No.
Code Function Action
0- No function is assigned No action
1ST Standby terminal ON :Standby, OFF: Free run
2F Forward-run command
ON :Forward run,
OFF:Deceleration stop
3R Reverse-run command
ON :Reverse run,
OFF:Deceleration stop (priority to
reverse run)
4JOG Jog run command ON :Jog run, OFF: Canceled
5AD2
Acceleration/deceleration 2 pattern
selection
ON :Acceleration/deceleration 2,
OFF:Acceleration/deceleration 1
6 SS1 Preset speed command 1
7 SS2 Preset speed command 2
8 SS3 Preset speed command 3
9 SS4 Preset speed command 4
Selection of preset speeds (up to 15
speeds) using 4 bits: SS1 to SS4
10 RST Reset command ON to OFF: Trip reset
11 EXT
Trip stop command from external input
device
ON :G Trip stop
12 PNL/TB
Operation panel / terminal board
switching
ON :Forced switching from operation
panel/internal potentiometer to
terminal board control
13 DB DC braking command ON :DC braking
14 PI Prohibition of PI control
ON :PI control prohibited
OFF: PI control permitted
15 PWENE Permission of parameter editing
ON :Edition of parameters permitted,
OFF:Edition of parameter prohibited （If
F700 is so set）
16 ST+RST
Combination of standby and reset
commands
ON :Simultaneous input of ST and RST
commands
17 ST+PNL/TB
Combination of standby and operation
panel/terminal board switching
ON :Simultaneous input of ST and
PNL/TB commands
18 F+JOG Combination of forward run and jog run
ON :Simultaneous input of F and JOG
commands
19 R+JOG Combination of reverse run and jog run
ON :Simultaneous input of R and JOG
commands
20 F+AD2
Combination of forward run and
acceleration/deceleration 2
ON :Simultaneous input of F and AD2
commands
21 R+AD2
Combination of reverse run and
acceleration/deceleration 2
ON :Simultaneous input of R and AD2
commands
22 F+SS1
Combination of forward run and preset
speed command 1
ON :Simultaneous input of F and SS1
commands
23 R+SS1
Combination of reverse run and preset
speed command 1
ON :Simultaneous input of R and SS1
commands
24 F+SS2
Combination of forward run and preset
speed command 2
ON :Simultaneous input of F and SS2
commands
25 R+SS2
Combination of reverse run and preset
speed command 2
ON :Simultaneous input of R and SS2
commands
26 F+SS3
Combination of forward run and preset
speed command 3
ON :Simultaneous input of F and SS3
commands
27 R+SS3
Combination of reverse run and preset
speed command 3
ON :Simultaneous input of R and SS3
commands
28 F+SS4
Combination of forward run and preset
speed command 4
ON :Simultaneous input of F and SS4
commands
