HYDRAULIC PUMP ASSEMBLY
Ref.
No.
Part No. Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
HG 70516
HG 70573
HG 50641
HG 50969
HG 51232
HG 2513027
HG 50273
HG 9004101-1340
HG 50095
HG 2513030
HG 70521
HG 50315
HG 51161
HG 50329
HG 50951
HG 70331
HG 2003014
HG 2003017
HG 51444
HG 2003087
HG 50551
HG 2003005
HG 2000015
HG 2510062
HG 70403
HG 2513043
HG 9005110-4400
HG 50408
HG 70525
HG 70589
Housing Kit
End Cap Kit
Straight Headless Pin
Hex Flng. Bolt, M8-1.25 x 60mm
Housing O-Ring
Charge Pump Kit
Gerotor Assembly
O-Ring
Socket Head Screw, M6 x 1.0-20mm
Bypass Valve Kit
Pumpshaft Kit
Ball Bearing, 17 x 40 x 12mm
Lip Seal
Retaining Ring
Spacer
Cylinder Block Kit
Block Spring
Block Thrust Washer
Valve Plate
Swash Plate
Ball Thrust Bearing
Trunnion Arm
Slot Guide
Check Valve Kit (.024” Orifice) port “A” on Left Hand Pump, port “B” on Right Hand Pump
Charge Relief Kit
Trunnion Seal with Retainer
Straight Thread Plug
Straight Headless Pin
Overhaul Seal Kit
System Check Relief Kit, port “B” on Left Hand Pump, port “A” on Right Hand Pump
* Common hardware which should be purchased locally. All bolts Grade 5 plated, all other fasteners zinc plated.
