Section 8
ELECTRICAL SYSTEM 26HP KAWASAKI LIQUID-COOLED
Ref.
No.
Part No. Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
483355
48298
483366
462069
48017-04
48017-03
461660
48798
483162
48788
04031-01
04020-01
481637
461952
482032
48030-09
481638
483029
04010-01
**
04001-44
04020-02
48029-15
48029-12
483619
483081
04021-10
424112
04010-11
483272
04063-23
04041-28
04030-05
04102-03
04010-12
04001-08
04030-03
04040-15
423909
481716
422534
481183
481670
483571
482588
483642
483629
Hourmeter
Fuse, 20 amp
Key, Ignition
Key Assembly w/Fob
Nut, Hex 5/8-32
Lockwasher, 5/8” Internal
Electric PTO Clutch GT3.5
Switch, Ignition
Switch, PTO
Relay
Lockwasher, #10 External Tooth
Nut, Hex #10-32
Switch, N/O
Panel, Instrument
Choke & Throttle Control - Kawasaki (Qty 2)
Clamp
Switch, Seat
Module, Interlock
Screw, #10-32 x .5” Phillips Head
Battery (Not Available Through Scag)
Bolt, Hex Hd. 1/4-20 x .5”
Nut, Hex 1/4-20
Cable, Battery Black (negative)
Cable, Battery Red (positive)
Wiring Harness, Main
Pulley, 5.45" OD x 1.125" Bore
Nut, Elastic Stop 5/16-18 Key
Mounting Bracket, Hour Meter
Screw, #10-32 x 1.5” Phillips Head
Adaptor, Wiring Harness
Key, 1/4 x 1/4 x 3-1/4”
Flatwasher, 7/16 (.469 x 1-3/4” x 1/4”)
Lockwasher, 7/16”
Bolt, Hex Hd. 7/16-20 x 2-1/4” UNF (61A Only)
Screw, #10-32 x 3/4”
Bolt, Hex Hd. 5/16-18 x 3/4”
Lockwasher, 5/16”
Flatwasher, 5/16 (.375 x .875 x .083")
Backing Plate
Rubber Pad, Clutch Stop
Plate, Backing
Water Temp. Gauge
Sender Unit, Water Temp
Cover, Sealed Double
Clip, Wire
Double Fuse Assembly, Sealed (incl. items 2, 43, 44, 46)
Fuse Holder
