37
R
Section 7
Replace the radiator cap. Push down on the cap and 3.
turn clockwise until it stops.
- NOTE -
The cooling system should be flushed and the
coolant replaced every 500 hours of operation or
annually. See your Scag dealer for proper coolant
replacement.
B. CLEANING THE RADIATOR DEBRIS SCREEN
After each day of operation, remove and clean the radiator
debris screen.
CAUTION
To avoid personal injury, always wear safety
glasses when using compressed air.
Release the debris screen latch and pull the debris 1.
screen towards the latch to remove. See Figure 7-9.
DEBRIS SCREEN
LATCH
Debris ScreenFigure 7-9.
Clean the debris screen with compressed air or a 2.
water hose.
- NOTE -
Check the radiator for excessive debris and clean
with compressed air. Never spray a hot engine
with water, use only compressed air to remove
debris.
Re-install the debris screen to the radiator and 3.
secure with the latch.
BODY, DECK, AND UPHOLSTERY7.12
CAUTION
Do not wash any portion of the equipment while it
is hot. Do not wash the engine; use compressed
air.
After each use, wash the mower and cutter deck. 1.
Use cold water and automotive cleaners. Do not use
pressure cleaners.
Do not spray electrical components.2.
Use a mild soap solution or a vinyl/rubber cleaner to 3.
clean the seat.
Repair damaged metal surfaces using Scag touch-4.
up paint available from your authorized Scag dealer.
Wax the mower for maximum paint protection.
