Section 8
FUEL AND HYDRAULIC SYSTEM
Ref.
No.
Part No. Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
482643
482644
482266-01
48572-02
48811
482573
482574
482266-01
48136-13
482548
04060-06
48572-04
48603-06
04001-20
04017-07
04030-02
04021-09
422969
04001-08
04030-03
04040-15
481164
481507
48829
421203
461479
48603-06
482277
48136-13
482571
482572
48136-13
483617
423912
48059-01
482212
48136-13
482800-02
04019-03
04041-07
48462-01
482798
482800-01
48604-03
482557
461970
482547
48309
483748
461698
48811
482708
04010-10
482774
**
482605
04001-11
482802
04001-17
48603-02
Pump, BDP-10A-316 (LH)
Pump, BDP-10A-419 (RH)
Elbow, 90 Degree 9/16" O-Ring x 3/8" Hose
Fitting, 1/2” JIC x 5/8" O-Ring
Hose, 3/8" Pushlock (Specify length)
Bushing
Fitting
Elbow, 90 Degree 9/16" O-Ring x 3/8" Hose
Hose Clamp, .69" Dia.
Hose Assembly
Roll Pin
Fitting, 1/2” JIC x 1/2” O-Ring
O-Ring
Bolt, Hex Hd. 3/8-16 x 1-1/2”
Bolt, Hex Hd. 1/4-20 x 1-1/4”
Lockwasher
Nut, Elastic Stop 3/8-16
Control Lever
Bolt, Hex Hd. 5/16-18 x 3/4”
Lockwasher, 5/16”
Flatwasher, 5/16 (.375 x .875 x .083")
Cap, Hydraulic Tank
Insert, Filler Neck
Control Block
Clamp Plate
Hydraulic Tank Assembly w/Fittings
O-Ring
Tee Fitting, O-Ring to Barb
Clamp, .69" Max. / .25" Min. Dia.
Bushing
Elbow, 0.38" Hose
Clamp
Fuel Hose, 1/4" ID Non-Perm.
Bracket Fuel Valve
Clamp, Fuel Hose 1/4" Hose ID
Valve, Fuel Shutoff
Clamp, .69" Max. / .25" Min. Dia.
Fitting, 9/16" O-Ring x 3/8" Hose
Nut, Serr. Flng. 5/16-18
Flatwasher, 3/8 (.391 x .938 x .105")
Oil Filter
Filter Head Assembly
Fitting, 3/4" O-Ring x 3/8" Hose
Plug, 9/16-18 O-Ring
Hose, Filter Inlet
Fuel Tank RH
Cap, Fuel Tank (incl. item #53)
Tank Bushing
Elbow, 90 Degree w/Screen
Fuel Tank LH
Hose, 3/8 Pushlock 15” Long
Cooler, Transmission
Screw, 1/4-20 x 2”
Gasket, Gas Tank Cap
Fuel Filter
Hose Assembly
Bolt, Hex Hd. 5/16-18 x 1-1/2”
Nipple, Oil Filter 1.0-12 UNF-2A x 1-1/4”
Bolt, Hex Hd. 5/16-18 x 2”
O-Ring, 3/4”
** Available through the individual engine manufacturer.
