Scag Power Equipment STWC61V-26KA-LC Lawn Mower User Manual



49
R
Section 8
STWC ROLL-OVER PROTECTION SYSTEM
Ref.
No.
Part No. Description
1
2
3
4
5
6
7
8
9
10
11
12
13
461956
04001-145
04021-19
483412
04040-13
481625-03
04062-06
483262
04021-19
424407
04001-145
04001-178
04040-11
STWC Foldable ROPS
Bolt, Hex Hd. 1/2-13 x 3-1/2”
Nut, Center Lock 1/2-13
Retractable Seat Belt
Flatwasher, 1/2 (.562 x 1.375 x .109")
Thumb Screw, 5/16-18 NC x 3/4”
Hair Pin, Cotter
Pin
Nut, Center Lock 1/2-13
Bracket, Stop
Bolt, Hex Hd. 1/2-13 x 3-1/2”
Bolt, Hex Hd. 7/16-20 x 1”
Flatwasher, 7/16 (.500 x 1.25 x .083")
