Section 8
Ref.
No.
Part No. Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
482340
461914
461923
04001-09
04030-03
483269
04040-15
04060-01
483238
04021-09
482330
04020-14
482623
04020-17
482331
43477
04001-20
04001-12
43602
423599
04001-17
*482452
*482794
04001-19
482099
04003-12
461770
461771
04019-03
04021-08
04001-18
43616
04021-10
48114-04
43559
49574
49573
04021-10
48100-06
04041-08
04050-02
423057
04017-16
04003-02
45918
481389
43477
04003-38
483250
Grip, Control Lever
Handle Bar, LH (Incl. item 1)
Handle Bar, RH (Incl. item 1)
Bolt, Hex Hd. 5/16-18 x 1”
Lockwasher, 5/16”
Knob
Flatwasher, 5/16 (.375 x .875 x .083")
Roll Pin, Spring 5/32 x 3/4”
Pivot, Control Lever
Nut, Elastic Stop 3/8-16
Rod End, 3/8-24 RH Female
Nut, 3/8-24 RH Thread
Rod, Pump Control Linkage
Nut, 3/8-24 UNF-2B LH Thread
Rod End, 3/8-24 LH Thread
Pin Retainer
Bolt, Hex Hd. 3/8-16 x 1-1/2”
Bolt, Hex Hd. 5/16-18 x 1-3/4”
Spacer, Pump Damper
Plate, Control Lever
Bolt, Hex Hd. 5/16-18 x 2”
Gas Damper
Gas Damper
Bolt, Hex Hd. 3/8-16 x 1”
Block, Clamping
Bolt, Carriage, 5/16-18 x 3/4”
Control Plate - LH w/Decal
Control Plate - RH w/Decal
Nut, Serr., Flng., 5/16-18
Nut, Elastic Stop 1/4-20
Bolt, Hex Hd. 3/8-16 x 3/4”
Shaft, Steering Control
Nut, Elastic Stop 5/16-18
Grease Fitting, 1/4-28 Self Tap
Spacer, Control
Control Lever Assy RH (Incl. 31 & 35)
Control Lever Assy LH (Incl. 31 & 35)
Nut, Elastic Stop 5/16-18
Bushing
Flatwasher, 3/4 (.766 x 1.25 x .059")
Retaining Ring, 3/4” Ext.
Bracket, Switch Actuator
Bolt, Hex Serr. Flng. 5/16-18 x 3/4”
Bolt, Carr. 1/4-20 x 3/4”
Bracket, Control Return
Spring
Pin Retainer
Bolt, Carriage 5/16-18 x 1-1/2”
Rubber Spacer
STEERING COMPONENTS
* Indentify the Gas Damper installed using the colored print and part number labeled on the Gas Damper. See Figure Below.
STABILUS
STAB-O-SHOC
DO NOT OPEN. DO NOT HEAT
OBSERVE DISPOSAL INSTRUCTIONS
8517PQ 194/07 A 2
482xxx
482452 - Damper (orange colored print)
482794 - Damper (blue colored print)
