61
R
Section 8
ELECTRICAL SYSTEM - KOHLER & KAWASAKI AIR-COOLED
Ref.
No.
Part No. Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
483355
48298
483366
462069
48017-04
48017-03
461660
48798
483162
48788
04031-01
04020-01
481637
461768
481544
482032
48030-09
481638
483029
04010-01
**
04001-44
04020-02
48029-15
48029-12
483618
483081
04021-10
424112
04010-11
482543
04063-23
04041-28
04030-05
04102-03
04010-12
04001-08
04030-03
04040-15
423909
481716
422534
482032
483629
483571
482588
483642
Hourmeter
Fuse, 20 Amp
Key, Ignition
Key Assembly w/Fob
Nut, Hex 5/8-32
Lockwasher, 5/8” Internal
Electric PTO Clutch GT3.5
Switch, Ignition
Switch, PTO
Relay
Lockwasher, #10 External Tooth
Nut, Hex #10-32
Switch, N/O
Panel, Instrument
Choke Control - Kohler (Qty 1)
Choke & Throttle Control - Kawasaki (Qty 2)
Clamp
Switch, Seat
Module, Interlock
Screw, #10-32 x .5” Phillips Head
Battery (Not Available Through Scag)
Bolt, Hex Hd. 1/4-20 x .5”
Nut, Hex 1/4-20
Cable, Battery Black (negative)
Cable, Battery Red (positive)
Wiring Harness, Main
Pulley, 5.45" OD x 1.125" Bore
Nut, Elastic Stop 5/16-18 Key
Mounting Bracket, Hour Meter
Screw, #10-32 x 1.5” Phillips Head
Adaptor, Wiring Harness
Key, 1/4 x 1/4 x 3-1/4”
Flatwasher, 7/16 (.469 x 1-3/4” x 1/4”)
Lockwasher, 7/16”
Bolt, Hex Hd. 7/16-20 x 2-1/4” UNF (61A Only)
Screw, #10-32 x 3/4”
Bolt, Hex Hd. 5/16-18 x 3/4”
Lockwasher, 5/16”
Flatwasher, 5/16 (.375 x .875 x .083")
Backing Plate
Rubber Pad, Clutch Stop
Plate, Backing
Throttle Control - Kohler & Kawasaki (Qty 1)
Fuse Holder
Cover, Sealed Double
Clip, Wire
Double Fuse Assembly, Sealed (incl. items 2, 42, 43, 44)
