Scag Power Equipment STWC61V-26KA-LC Lawn Mower User Manual



47
R
Section 8
SHEET METAL COMPONENTS
Ref.
No.
Part No. Description
Ref.
No.
Part No. Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
461918
04001-73
482938
04019-04
461989
482939
43462
481389
**
423571
482553
04003-12
423556
04060-01
04019-03
04001-19
482552
04001-59
04019-02
451896
04021-10
483386
482616
482618
482616
482617
482937
423557
04021-09
04001-19
48566
451827
451826
481559
04021-20
48668
482028-01
481025
04021-07
451658
04001-167
43583
9278
482619
482622
482620
482621
48114-10
Main Frame Assembly w/Decals
Bolt, Hex Hd. 5/16-18 x 3-3/4”
Back Cover
Nut, Serr. Flng. 3/8-16
Plate, Seat Mounting
Cushion Cover
Pin Retainer, Spring
Spring
Battery (not available through Scag)
Battery Cover
Battery Hold Down Pad
Bolt, Carr. 5/16-18 x 3/4”
Battery Box
Roll Pin, Spring 5/32 x 3/4”
Nut, Serr. Flng. 5/16-18
Bolt, Hex Hd. 3/8-16 x 1”
Pad, Rubber
Bolt, Hex Hd. 1/4-20 x 1-1/4”
Nut, Serr. Flng. 1/4-20
Seat Base Support
Nut, Elastic Stop 5/16-18
Seat Assembly w/Adj. Rails & Seat Belt
Armrest Cover
Armrest, RH
Armrest Cover
Armrest, LH
Seat Track Set
Footplate
Nut, Elastic Stop 3/8-16
Bolt, Hex Hd. 3/8-16 x 1”
Cable, Seat Stop
Weldment, Caster Support (61V)
Weldment, Caster Support (52V)
Cap, Grease
Nut, Elastic Stop 1.0-14
Bearing Set
Plug, 1/4-28
Seal, 2.0” OD x 1.625” ID
Nut, Elastic Stop 1/2-13
Yoke, Front Caster Wheel
Bolt, Hex Hd. 1/2-13 x 9-1/2”
Sleeve
Caster Wheel Assembly (Incl. 41 thru 45)
Tire, 13 x 6.5-6 Smooth
Seal
Rim (Incl. Item 45)
Roller Bearing
Fitting, Grease
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
423575
423764
482633
43584
04001-28
04021-11
04030-05
04001-06
451580
04003-04
423912
424112
04001-32
04030-04
04110-03
451840
04021-05
483371
451897
04001-100
424584
04001-09
Mounting Bracket, Oil Tank
Mounting Bracket, Fuel Tank
Seat Pan
Spacer, Caster Wheel
Bolt, Hex Hd. 7/16-14 x 1-1/4”
Nut, Elastic Stop 7/16-14
Lockwasher, 7/16”
Bolt, Hex Hd. 1/4-20 x 5/8”
Support Weldment, Oil Cooler
Bolt, Carriage 5/16-18 x 1”
Bracket, Fuel Valve
Bracket, Hour Meter
Bolt, Hex Hd. 3/8-16 x 1-1/4”
Lockwasher. 3/8” Spring
U-Nut, 3/8-16
Support Weld, Oil Cooler - 26hp Kaw.
Locknut, 3/8-16 Center Lock
Spring, Seat Latch
Seat Latch Weldment
Bolt, Hex Hd. 3/8-16 x 6”
Seat Stop
Bolt, Hex Hd. 5/16-18 x 1”
