Section 7
MAINTENANCE CHART - RECOMMENDED SERVICE INTERVALS (CONT'D)
HOURS
PROCEDURE COMMENTS
BREAK-IN
(FIRST 10)
8 40 100 200 500
X
Apply grease to fittings See paragraph 7.2
X
Check hardware for tightness
X
Change engine oil filter See paragraph 7.4
X
Check hydraulic oil level See paragraph 7.3
X
Replace engine fuel filter See paragraph 7.5
X
Drain hydraulic system and
replace hydraulic oil
Use SAE 20W50 Motor Oil.
See paragraph 7.3
X
Replace hydraulic oil filter See paragraph 7.3
X
Adjust electric PTO clutch See Scag Dealer
X
Change coolant See paragraph 7.11
LUBRICATION7.2
GREASE FITTING LUBRICATION CHART (SEE FIGURE 7-1)
LOCATION LUBRICATION INTERVAL LUBRICANT
NO. OF
PLACES
1 Caster Wheel Pivot * 500 Hours/Yearly Chassis Grease 2
2 Caster Wheel Bearings 100 Hours/Monthly Chassis Grease 2
3 Brake Actuator 200 Hours/Monthly Chassis Grease 2
4 Cutter Deck Bellcranks 100 Hours/Bi-Weekly Chassis Grease 4
5 Cutter Deck Pusharms 100 Hours/Bi-Weekly Chassis Grease 2
6 Control Pivot 100 Hours/Bi-Weekly Chassis Grease 2
6 Cutter Deck Spindle 40 Hours/Weekly +Lithium MP White Grease 2125 3
7 Brake Handle 200 Hours/Monthly Chassis Grease 1
+ Compatible Greases: Mobilix #2 found at Mobil Service Stations
Ronex MP found at Exxon Service Stations
Super Lube MEP #2 & Super Stay-M #2 found at Conoco Stations
Shell Alvania #2 found at Shell Service Stations
Lidok EP #2 found at industrial shops
Timken Lithium Multi-Use #2 found at industrial shops
* PROCEDURE: Remove grease cap, part number 481559. Remove plug, part number 482028-01, and
install grease zerk. Apply grease to the fitting until new grease appears at the top of the caster extension.
Remove the grease zerk and reinstall the plug. Reinstall the grease cap. Special tool, part number 47007, is
recommended for use in the installation of the grease cap.
