Scag Power Equipment STWC61V-26KA-LC Lawn Mower User Manual



41
R
Section 8
Ref.
No.
Part No. Description
Ref.
No.
Part No. Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
461858
43686
04019-04
481625-01
481632
04003-26
422478
04017-27
04043-06
04021-05
461845
04001-11
04001-12
04021-10
04020-09
45944
04001-41
48038
04001-154
04063-08
483246
04043-04
04001-176
04019-03
04001-51
48100-15
04030-03
04040-15
04001-136
04021-09
04001-31
483247
424409
04110-03
461663
43589
481024
481022
48114-04
48677
43644
43312
43296
481025
43297
481035
43590
482878
483210
48224
461940
Cutter Deck Velocity Plus
Boss, Spring Anchor
Nut, 3/8-16 Serr. Flng.
Wing Nut, 3/8-16
Anti-Scalp Wheel
Bolt, Carriage 3/8-16 x 4”
Bracket, Anti-Scalp Wheel
Bolt, Serr. Flng. 3/8-16 x 1”
Flatwasher, 5/8” Hardened
Locknut, 3/8-16 Center Lock
Discharge Chute
Bolt, Hex Hd. 5/16-18 x 1-1/2”, Rear
Bolt, Hex Hd. 5/16-18 x 1-3/4”, Front
Nut, Elastic Stop 5/16-18
Nut, 5/8-11 UNC
Shaft, Roller
Bolt, Hex Hd. 5/8-11 x 9-1/2”
Roller, Rear
Bolt, Hex Hd. 5/16-18 x 4-3/4”
Key, 1/4 x 1/4 x 2”
Spring, Idler LH
Flatwasher, 3/8”
Bolt, Hex Hd. 5/16-18 x 1-3/4” Grd. 8
Nut, Serr. Flng. 5/16-18
Bolt, Hex Hd. 3/8-16 x 3-3/4”
Bushing, .376" ID Oilite®
Lockwasher 5/16”
Flatwasher 5/16”
Bolt, Hex Hd. 3/8-16 x 1-1/2” Grd. 8
Nut, Elastic Stop 3/8-16
Bolt, Hex Hd. 3/8-16 x 2-1/2”
Spring, Idler RH
Bracket, Spring Anchor LH 52V
U-Nut, 3/8-16
Spindle Assembly
Shaft, Spindle
Seal Upper
Bearing Assembly
Grease Fitting
Valve, Grease Relief
Housing, Spindle
Spacer, Outside
Spacer, Inside
Seal, Lower
Bushing, Bottom
Nut, Special 1-1/16 - 18
Spacer, Spindle
Cutter Blade 18”
Pulley, Idler 5” Dia.
Bearing
Idler Arm Assy.
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
43689
424323
48926
461946
04001-172
483284
424208
451240
461516
04020-16
04021-13
48763
04001-79
48114-04
483242
04001-09
483378
424840
04003-23
04021-22
04043-04
483240
48181
483285
483167
461929
04003-40
04040-11
04021-11
424367
04030-03
424377
04001-136
04001-19
04021-04
483176
43689
04003-12
04040-04
Idler Pivot
Belt Cover (52V)
Hub, Tapered 1-1/8” Bore
Idler Arm
Bolt, Hex Hd. 1/4-20 x 1” Grd. 8
Pulley 5.35”
Turbo Baffle, Bolt On
Push Arm Shaft
Push Arm (Incl. 64, 60, 62)
Nut, 5/8-18 UNF
Nut, Elastic Stop 5/8-11
Rod End, 5/8" Male RH Thread
Bolt, Hex Hd. 5/8-11 x 4-1/2”
Grease Fitting, 90 Degree
Belt, Cutter Deck Drive
Bolt, Hex Hd. 5/16-18 x 1"
Spring, Discharge Chute
Baffle Weldment
Bolt, Carriage 3/8-16 x 1”
Nut, Elastic Stop 5/16-18 Grd. 8
Flatwasher 3/8”
Belt, RH Cutter Deck
Pulley, Idler 5” Dia.
Pulley, Double Groove
Bolt, Special
Lever Assy., Deck Level
Bolt, Carriage 7/16-14 x 1-1/4”
Flatwasher, 7/16 (.500 x 1.25 x .083")
Nut, Elastic Stop 7/16-14
Dust Shield
Lockwasher 3/8”
Bracket, Spring Anchor RH
Bolt, Hex Hd. 3/8-16 x 1-1/2” Grd. 8
Bolt, Hex Hd. 3/8-16 x 1”
Nut, Center Lock 5/16-18
Wear Pad
Idler Pivot
Bolt, Carriage 5/16-18 x 3/4”
Flatwasher, 5/16”
52V CUTTER DECK
