Section 8
BRAKE COMPONENTS
Ref.
No.
Part No. Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
04019-06
48807
04001-08
04001-163
04001-52
04021-19
483190
04063-25
461438
483644
482061
48680
04061-06
04028-02
482413
481850
482414
481851
482194
481852
04004-46
04020-14
423279
04064-16
04069-01
451970
451971
48114-04
04020-25
04050-01
04021-10
04041-07
04001-187
04001-166
04061-02
04001-20
451463
04021-09
48544
04064-02
48343-04
482102
04019-04
461509
04001-22
04020-17
422483
45974
43495
04008-01
Nut, Serr. Flng. 1/2-13
Spring
Bolt, Hex Hd. 5/16-18 x 3/4”
Bolt, Hex Hd. 1/2-13 x 3-3/4”
Bolt, Hex Hd. 1/2-13 x 2-1/2”
Nut, 1/2-13 Center Lock
Wheel Motor, Hydro-Gear
Key, Woodruff 5/16 x 1”
Wheel Hub Assembly
Brake Band Assembly
Bushing, Self Align
Nut, Hex Castle 1.0-20 UNEF
Cotter Pin, 9/64 x 1-1/2”
Lug Nut, 1/2-20
(52”) Wheel Assembly 23 x 9.5 -12
(61”) Wheel Assembly 24 x 12 - 12
(52”) Rim
(61”) Rim w/Stem
(52”) Tire 23 x 9.5 - 12
Tire 24 x 12 - 12
Brake Rod Stud, 3/8-24 x 8-1/8”
Nut, 3/8-24 UNF
Plate Weldment, Motor Backing
Clevis Pin, 3/8 x 1.93”
Pin, Rue Cotter 3/8” Dia.
Brake Linkage LH
Brake Linkage RH
Grease Fitting, 1/4-28
Nut, 3/8-24 UNF
Retaining Ring, .625" Ext.
Nut, Elastic Stop 5/16-18
Flatwasher, 3/8 (.391 x .938 x .105")
Bolt, Hex Hd. 1/2-13 x 2-1/2” Grd. 8
Bolt, Hex Hd. 3/8-24 x 3-3/4”
Cotter Pin, 3/32 x 3/4”
Bolt, Hex Hd. 3/8-16 x 1-1/2”
Brake Shaft
Nut, Elastic Stop 3/8-16
Rod End, 3/8-24 LH Thread
Clevis Pin, 3/8 x 1.06"
Clevis, 3/8-24
Grip, Brake Lever
Nut, Serr. Flng. 3/8-16
Brake Lever (Incl. item 36)
Bolt, Hex Hd. 3/8-16 x 2-3/4”
Nut, 3/8-24 UNF-2B LH Thread
Lever, Brake
Shaft Weldment, Pivot
Pin, Pivot
Bolt, Serr. Flng. 1/2-20 x 4.563”
