Section 8
CUTTER DECK CONTROLS
Ref.
No.
Part No. Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
482624
04020-28
481766
04050-10
483062
43487
423463
04001-22
43668
04021-09
461874
422346
04014-03
422381
04003-04
422380
483177
04021-05
04040-09
04019-04
04001-32
43678
04061-07
04019-04
04001-20
04019-04
04021-09
48540
48114-04
483181
461929
04004-45
04067-09
481547
04020-09
43679
04001-155
481765
04001-77
43572
04021-02
43630
04020-27
04021-10
45904
45905
04041-14
04050-08
04062-04
481477
Rod, Deck Lift Linkage
Nut, Jam 1/2-20 LH Thread
Rod End, 1/2-20 Female LH Thread
Retaining Ring, 1/2” Ext. “E”
Slide, Deck Height Adjust
Pin, Deck Lift
Bracket, Cutting Height Adjustment
Bolt, Hex Hd. 3/8-16 x 2-3/4”
Bushing .502" OD
Nut, Elastic Stop 3/8-16
Lever, Deck Latch
Slide, Cutting Height
Capscrew, 5/16-18 x 3” Flathead Hex Socket Grd. 8
Guide, Short
Bolt, Carriage 5/16-18 x 1”
Guide, Long
Spring, Helper
Nut, 3/8-16 Center Lock
Flatwasher, 5/8 (.656 x 1.312 x .095")
Nut, 3/8-16 Serr. Flng.
Bolt, Hex Hd. 3/8-16 x 1-1/4”
Swivel Joint LH
Cotter Pin, 3/16 x 1”
Nut, Serr. Flng. 3/8-16
Bolt, Hex Hd. 3/8-16 x 1-1/2”
Nut, Serr. Flng. 3/8-16
Nut, Elastic Stop 3/8-16
Chain
Grease Fitting, 1/4-28 Self Tap
Torsion Spring
Lever Assy., Deck Level
Stud, 1/2-13 x 20”
Pin
Lanyard
Nut, 5/8-11 UNC
Swivel Joint RH
Bolt, Hex Hd. 1/2-13 x 5”
Rod End, 1/2-20 Female RH Thread
Bolt, Hex Hd. 3/8-16 x 3-1/2”
Spacer
Locknut, 1/4-20
Spacer
Nut, 1/2-20 UNF-2B RH Thread
Nut, Elastic Stop 5/16-18
Lift Bellcrank Weldment, LH Rear
Lift Bellcrank Weldment, RH Rear
Flatwasher, 1.0 (1.062 x 1.5 x .048")
Retaining Ring, 1” Ext.
Hair Pin Cotter, .177" x 3-1/4”
Grip, Deck Latch Lever
