2000 Owner’s Manual
1) Before filling your spa, install the hose bib that is included in the
owner’s manual packet located in the equipment compartment.
Screw the hose bib onto the male fitting located at the bottom of the
spa on the pedestal, to the lower left of the equipment compartment.
Close the valve on the side of the hose bib and screw the cap onto
the end of the hose bib.
2) Check the pump unions to be sure that they are tight to prevent the
possibility of leakage in the equipment compartment. Also, open the
bleeder valve located next to the sidewall of the skimmer area to
allow air to escape from the pump(s).
3) Fill your spa with water to a level of one to two inches above the
bottom of the tile line.
4) Remove the two shipping bolts located on the front of the pump
mount and ensure that the gate valves on the pump are in the open
position (handles fully extended).
5) Turn on the circuit breaker. Dashed lines will appear for 30 seconds
on the LCD followed by the current water temperature flashing.
Press the UP or DOWN pads to set your desired spa temperature. If
your spa is equipped with the CrystalZone Water Management
System and there is a call for heat, the circulation pump will then
activate and turn on the heater. If CrystalZone is not installed, and
there is a call for heat, the low speed pump will come on with the
heater. One minute after start-up, the internal time clock is auto-
matically set to initiate the first filtration cycle. The system factory
default is two, one hour cycles. Let the system run for 30 to 45 sec-
onds to prime the pump(s). If there is no jet action, then the water
level is too low, the gate valves are closed or there is air trapped in
the plumbing lines. To eliminate the trapped air, turn the pump(s)
on and off several times to force the trapped air through the pump(s).
If there is still no jet action, and the bleeder valve has been open for
some time, turn off the pump(s) and loosen the top pump union
slightly to let any trapped air escape. Re-tighten the pump union
INITIAL ST ART-UP FOR THE
AURORA HP , INTERLUDE, ARENA
AND TRIAD
