DCA-800SSK (STD) — OPERATION AND PARTS MANUAL — REV. #4 (06/03/10) — PAGE 99
DCA-800SSK — FUEL TANK ASSY.
FUEL TANK ASSY.
NO PART NO PART NAME QTY. REMARKS
1 C5364000303 FUEL TANK 1
2 0605505030 CAP, FUEL TANK ..................................... 1 .........REPLACES 0605505005
2A 0601850590 KEY, FUEL TANK CAP 1
3 0810105400 FUEL FILTER 1
4 0264100425 HOSE, FUEL GAUGE 1
5 0605515079 HOSE BAND 2
6 7435523104 TANK BAND 2
7 0805003414 PAD, TANK BAND 4
8 0017108020 HEX. HEAD BOLT 2
9 0207308000 HEX. NUT 2
10 0222100600 TANK SHEET 6
11 0130206000 STREET ELBOW, 1/2 3
12 7525512104 DRAIN PIPE 1
13 7525516504 BRACKET 1
14 0019108030 HEX. HEAD BOLT 2
15 0205008000 HEX. NUT 2
16 0042308000 LOCK WASHER 2
17 0042408000 PLAIN WASHER 2
18 0603325011 VALVE 1
19 0132006000 PLUG, 1/2 3
20 0605503009 FUEL SENSOR 1
21 0802120604 PACKING 1
22 0605501050 UNIT, FUEL .............................................. 1 ......... 52000-KA9810
23 0602021155 PACKING .................................................. 1 .........52391-KW3700
25 0022905015 MACHINE SCREW 5
25 0845039604 RUBBER SEAL 1
26 7435512104 LONG NIPPLE 2
27 0605511033 THREE WAY VALVE 2
28 0131506000 NIPPLE, 1/2 2
29 0130406000 T JOINT, 1/2 2
30 0602022293 HOSE JOINT 1
31 0602022203 HOSE JOINT 3
32 6185517204 HOSE JOINT 2
33 0191504300 SUCTION HOSE 1
34 0191302500 SUCTION HOSE 1
35 0191301100 SUCTION HOSE 1
36 0191004500 RETURN HOSE 1
37 0191002500 RETURN HOSE 1
38 0191001100 RETURN HOSE 1
39 0605515032 HOSE BAND 2
40 0605515014 HOSE BAND 6
41 0605515155 HOSE BAND 4
42 C5358300104 CLAMPER 1
43 0017110025 HEX. HEAD BOLT 2
