DCA-800SSK (STD) — OPERATION AND PARTS MANUAL — REV. #4 (06/03/10) — PAGE 89
DCA-800SSK — ENGINE OPERATING PANEL ASSY.
ENGINE OPERATING PANEL ASSY.
NO PART NO PART NAME QTY. REMARKS
1 C5484000002 SUPPORT LEG 1
2 0017112045 HEX. HEAD BOLT 4
2 0030012000 HEX. NUT 4
2 0041212000 PLAIN WASHER 4
3 0017110025 HEX. HEAD BOLT 2
3 0207010000 HEX. NUT 2
4 C5352100203 OPERATING PANEL .................................... 1 ..... UP TO S/N 3698625
4 C5352100213 OPERATING PANEL .................................... 1 ..... S/N 3698626~
5 0017108020 HEX. HEAD BOLT 4
6 0017108020 HEX. HEAD BOLT 3
7 8085182004 RUBBER COVER 3
8 8085183004 SET FRAME, RUBBER COVER 3
9 0017106020 HEX. HEAD BOLT 18
10 0602101016 BATTERY SWITCH ...................................... 1 ..... 0315251001
11 7522258304 BRACKET, BATTERY SWITCH 2
12 0017106030 HEX. HEAD BOLT 4
12 0207006000 HEX. NUT 4
13 0025006016 MACHINE SCREW 4
13 0042306000 LOCK WASHER 4
13 0042506000 PLAIN WASHER 4
14 6008155390 STARTER SWITCH ...................................... 1 ..... UP TO S/N3699247 REPL. 0602100049
14A 615 KEY, STARTER SWITCH ............................. 1 ..... UP TO S/N3699247
15 0806410000 EMERGENCY STOP BUTTON ................... 1 ..... REPLACES 0602104045
16 6008153730 PREHEAT INDICATOR ................................ 1 ..... REPLACES 0602102055
17 0602120054 TACHOMETER ............................................. 1 ..... 25000-KX4110
18 0602120173 CABLE, TACHOMETER ............................... 1 ..... 62500-KA4110 L=4000
19 0602122060 OIL PRESSURE GAUGE ............................. 1 ..... 4200-KX1410
20 0602122200 UNIT, OIL PRESSURE ................................. 1 ..... 53000-AC0101
21 0602123061 WATER TEMPERATURE GAUGE ............... 1 ..... 40000-KX0910
22 0602123206 UNIT, WATER TEMPERATURE ................... 1 ..... 51400-KS0600
23 0602121052 CHARGING AMMETER ............................... 1 ..... 43000-KV0300
24 0602125060 FUEL GAUGE ............................................... 1 ..... 41000-KW0110
25 0602040692 INDICATOR, AIR CLEANER ........................ 2 ..... RBX00-2254
26 6203306104 SOCKET 2
27 0603301000 ELBOW UNION ............................................ 2 ..... UP TO S/N 3702700
27 0603301030 ELBOW UNION ............................................ 2 ..... S/N 3702701~
28 0603300000 HALF UNION ................................................ 2 ..... UP TO S/N 3702700
28 0603300040 HALF UNION ................................................ 2 ..... S/N 3702701~
29 0603302000
SLEEVE ........................................................ 4 ..... UP TO S/N 3702700
29 0603302020 SLEEVE ........................................................ 4 ..... S/N 3702701~
30 0603303000 NUT ............................................................... 4 ..... UP TO S/N 3702700
30 0603303030 NUT ............................................................... 4 ..... S/N 3702701~
31 0190002900 NYLON PIPE ................................................. 2 ..... UP TO S/N 3702700
31 0190302500 NYLON PIPE, LEFT SIDE ............................ 1 ..... S/N 3702701~
31 0190302800 NYLON PIPE, RIGHT SIDE .......................... 1 ..... S/N 3702701~
32 0602115008 LED MODULE ............................................... 1 ..... V33676A
33 0602103091 ALARM LAMP, OIL FILTER .......................... 1 ..... REPLACES 0602103090
33 0601810244 BULB 1
34 0601830710 ENGINE SPEED SWITCH ............................ 1 ..... S-301T
35 0601850267 GROMMET 1
36 0601830448 PREHEAT BUTTON, AH25FB101 ............... 1 ..... S/N3699248~
