DCA-800SSK (STD) — OPERATION AND PARTS MANUAL — REV. #4 (06/03/10) — PAGE 77
DCA-800SSK — CONTROL PANEL ASSY.
CONTROL PANEL ASSY.
NO PART NO PART NAME QTY. REMARKS
1 C5224000503 CONTROL PANEL 1
2 C5224000403 CONTROL PANEL 1
3 0605011211 PIN 4
4 0601810476 OFF LAMP, CIRCUIT BREAKER ............ 1.......APN133-G
4 0601810235 BULB ....................................................... 1.......LS-3
5 0601810467 ON LAMP, CIRCUIT BREAKER .............. 1.......APN133-R
5 0601810235 BULB ....................................................... 1.......LS-3
6 0601830498 OFF SWITCH, CIRCUIT BREAKER ....... 1.......AH30-FR10
7 0601831224 ON SWITCH, CIRCUIT BREAKER ......... 1....... AH30-FB10
8 0601830780 THROTTLE LEVER ................................. 1.......ARNS1-2020 UP TO S/N 3699247
8 0601850267 GROMMET .............................................. 1.......S/N 3693886~
9 0601800480 FREQUENCY METER ............................ 1.......PAK-100 0~1500A 0~3000A
10 0601800795 AC AMMETER ........................................ 1....... SL-2 AS
11 0601801040 CHANGE-OVER SWITCH, AMMETER ... 1.......PCK-100 0~6000V
12 0601800252 AC VOLTMETER ..................................... 1....... SL-2 VS
13 0601801041 CHANGE-OVER SWITCH, VOLTMETER 1....... SP-132DC 220V
14 0601810072 PILOT LAMP ........................................... 1....... CT-13W
14 0601810261 BULB 1
15 0601840073 RHEOSTAT (VOLTAGE REGULATOR) ..... 1....... RA20A2SE102BJ 2W 1K OHMS
16 0601840121 KNOB 1
17 ECU9988N600/800 ENGINE CONTROLLER .......................... 1....... S/N 3699248~
17 0602202471 SEALED CABLE ..................................... 1.......S/N 3699248 ~REPL.060220254+0601827395
17 DYNT11200 SPEED SENSOR .................................... 1.......S/N 3699248~ REPLACES 0602120498
18 0601831340 SWITCH .................................................. 1.......S/N 3692434 TO 3698625
18 0601830765 SWITCH, S303T ...................................... 1....... S/N 3698626~
19 0601810161 PANEL LIGHT 1
19 0601810214 BULB 1
20 0207004000 HEX. NUT 2
21 0601830710 SWITCH, PANEL LIGHT 1
22 C9221100004 HEX. HEAD BOLT 4
22 0040008000 LOCK WASHER 4
22 0041208000 PLAIN WASHER 4
22 0080200007 SNAP RING 4
