DCA-800SSK (STD) — OPERATION AND PARTS MANUAL — REV. #4 (06/03/10) — PAGE 107
DCA-800SSK — ENCLOSURE #2 ASSY.
ENCLOSURE #2 ASSY.
NO PART NO PART NAME QTY. REMARKS
29 0805011304 STOPPER, DOOR 1
30 0805011204 STOPPER, DOOR 1
31 0205006000 HEX. NUT 4
31 0042306000 LOCK WASHER 4
31 0042406000 PLAIN WASHER 4
32 M9110100204 HINGE ...................................................... 2 .........REPLACES 0845047104
32 0845045004 WASHER 2
33 M9110100304 HINGE ...................................................... 2 .........REPLACES 0845047204
33 0845045004 WASHER 2
34 0019208020 HEX. HEAD BOLT 4
35 0845031504 CAP 4
36 0601850097 STOPPER 4
37 0021008025 MACHINE SCREW 4
38 C5464200203 ROOF PANEL 1
38 C5494500003 LINING 1
39 C5464200003 ROOF PANEL ........................................... 1 .........UP TO S/N 3707480
39 C5464200103 ROOF PANEL ........................................... 1 .........S/N 3707481~
39 C5494500003 LINING 1
40 C5464200103 ROOF PANEL ........................................... 1 .........UP TO S/N 3707480
40 C5464200803 ROOF PANEL ........................................... 1 .........S/N 3707481~
40 C5494500003 LINING 1
41 0207008000 HEX. NUT 18
42 C5464200504 PANEL 1
42 C5494500003 LINING 1
43 C5464200604 GUIDE 1
44 0207008000 HEX. NUT 20
45 0017108020 HEX. HEAD BOLT 4
46 C5464200404 PANEL 1
46 C5494500003 LINING 1
47 C5464200304 PANEL 1
47 C5494500003 LINING 1
48 0207008000 HEX. NUT 10
49 0017108020 HEX. HEAD BOLT 4
50 C5464400004 COVER, ROOF PANEL 1
50 C5494500104 LINING 1
51 0017108020 HEX. HEAD BOLT 12
52 0019210025 HEX. HEAD BOLT 34
53 0019112030 HEX. HEAD BOLT 4
53 0042312000 LOCK WASHER 4
53 0042412000 PLAIN WASHER 4
54 0600500090 EMBLEM 1
55 0021106016 MACHINE SCREW 2
56 B9114500104 DOOR POCK
ET 1
57 0207006000 HEX. NUT 4
58 C5464500104 BRACKET ................................................ 1 .........S/N 3707481~
59 C5464500204 BRACKET ................................................ 1 .........S/N 3707481~
