DCA-800SSK (STD) — OPERATION AND PARTS MANUAL — REV. #4 (06/03/10) — PAGE 101
ENCLOSURE #1 ASSY.
NO PART NO PART NAME QTY. REMARKS
1 C5414000002 BASE 1
2 7525116004 FLOOR PANEL 1
3 0019110030 HEX. HEAD BOLT 4
3 0042310000 LOCK WASHER 4
3 0042410000 PLAIN WASHER 4
4 C5414100004 FLOOR PANEL 1
5 0019208020 HEX. HEAD BOLT 12
6 C5414600004 GUIDE PANEL, AIR 1
7 0017108020 HEX. HEAD BOLT 4
8 C5424001303 FRONT FRAME 1
8 C5494100003 LINING 1
9 C5424000803 FRONT FRAME 1
9 C5494100003 LINING 1
10 C5424000003 FRONT FRAME 1
11 0017108020 HEX. HEAD BOLT 6
12 C5424000202 FRONT FRAME 1
12 C5494100003 LINING 1
13 C5424000302 FRONT FRAME 1
13 C5494100003 LINING 1
14 0017108020 HEX. HEAD BOLT 26
15 C5424000603 GUIDE PANEL, AIR 1
15 C5494100003 LINING 1
16 C5424000403 GUIDE PANEL, AIR 1
16 C5494100003 LINING 1
17 C5424000503 GUIDE PANEL, AIR 1
17 C5494100003 LINING 1
18 0017108020 HEX. HEAD BOLT 36
19 C5424000704 GUSSET 2
20 0017110025 HEX. HEAD BOLT 8
21 C5327100003 BREATHER PIPE 1
22 0017110025 HEX. HEAD BOLT 2
23 0019210025 HEX. HEAD BOLT 10
24 7525125403 COVER, FRONT FRAME 1
25 7525125103 COVER, FRONT FRAME 1
25 C5494100304 LINING 1
26 0019208020 HEX. HEAD BOLT 36
27 0845042703 FILLER BRACKET 1
28 0019208020 HEX. HEAD BOLT 4
29 7525125304 COVER 1
30 0019106020 HEX. HEAD BOLT 6
30 0042306000 LOCK WASHER 6
30 0042406000 PLAIN WASHER 6
DCA-800SSK — ENCLOSURE #1 ASSY.
