DCA-800SSK (STD) — OPERATION AND PARTS MANUAL — REV. #4 (06/03/10) — PAGE 49
DCA-800SSK — GENERATOR SHUT-DOWN PROCEDURE (AUTO)
When starting generator in AUTO mode use the "
Manual
Start-up" procedure except where noted (see below).
1. Perform steps 1 through 4 in the
Before Starting
section
(page 45) as outlined in the
Manual Starting
Procedure
.
Figure 67. Engine Speed Switch (High)
Figure 68. Off/Manual Auto Switch (AUTO)
4. Place the Off/Manual/Auto switch (Figure 68) on the
MPEC unit to the AUTO position.
NOTE
When the generator is set in the “
AUTO ” mode, the generator will
automatically start
in the event of
commercial power falling below a
prescribed level by means of a
contact closure that is generated
automatically by a transfer switch.
2. Set the
battery ON/OFF switch
(Figure 66) to the “ON”
position.
Figure 66. Battery ON/OFF Switch
3. Set the engine speed switch (Figure 67) to the “High”
position.
5. Continue operating the generator as outlined in steps
11 thru 19 (pages 46-47).
Starting (Auto Mode)
Before connecting this generator to any
building’s electrical system, a
licensed
electrician
must install an
isolation
(transfer)
switch
. Serious damage to the
building’s electrical system may occur
without this transfer switch.
DANGER - ELECTRICAL SYSTEM HAZARDS
When connecting the generator to a isolation (transfer)
switch, ALWAYS have power applied to the generator's
internal battery charger. This will ensure that the engine
will not fail due to a dead battery.
When running the generator in the AUTO mode, remember
the generator can start up at any time without warning.
NEVER attempt to perform any maintenance when the
generator is in the auto mode.
WARNING - AUTO MODE MAINTENANCE
CAUTION - BACKUP GENERATOR USE
The
Engine Speed Switch
must be set to the “High”
position when running in the
Auto-Start
mode. Failing to
set the switch in the proper position can result in damage
to your generator when it turns on.
CAUTION - ENGINE SPEED SWITCH
